Running RAID Assist
Figure 4-22. Manual Configuration – Disk Arrays
Each disk array is represented by two lines in the Disk Arrays area of the
screen (upper left, Figure 4-22). Logical drives (if any have already been
configured) display on the right side.
Do the following:
1. Select an unused drive and drag it to the Disk Array A0 section. The
drive will be part of a disk array referred to as "A0."
2. Select other unused drives and drag them to Disk Array A0, or click the
Add Array button to create a row for Disk Array A1 (then A2, A3,
etc.), then drag unused drives to A1 (or A2, A3, etc.) if you so desire.
Note
Multiple drives can be added by holding down Ctrl
while clicking drives, then dragging the selected set to
a Disk Array section.
3. If you want to manually configure a hot spare, click an unused drive,
then click the Make Spare button. If you want a dedicated hot spare,
drag and drop the hot spare to the desired disk array.
4. If you want to start over, click the Clear All button and start again.
4-24 GAM Client User's Guide
