Enclosure Monitoring and Management

Enclosure Monitoring and Management
The Controller View window contains an Enclosure button with a status
light. The Green square indicates OK, the Yellow circle indicates Critical
status, and a Red X indicates failed status. You can monitor information,
status, and additional details about enclosures by clicking the Enclosure
button in Controller View. Alternatively, you can select Enclosure
Information from the Administration menu as shown in
Figure 5-13.
Figure 5-13. Select "Enclosure Information"
The Enclosure Information dialog box is displayed with the Information
page active (Figure 5-14).
5-16 GAM Client User's Guide
