Acc Set Mode - Icom IC-7600 Instruction Manual

■ ACC set mode

USB Audio SQL
Sets the squelch condton of the USB audo whch
s output from the [USB] (B) connector on the rear
panel.
The same audo sgnals are output from [USB] (B)
and the ACC sockets.
• The beep tones and the voce syntheszer announce-
ments are not output.
• The receved audo output level cannot be adjusted wth
the [AF] control.
USB MOD Level
Sets the nput modulaton level of the [USB] (B) con-
nector from 0% to 100% n 1% steps. (default: 50%)
DATA OFF MOD
Selects the desred connector(s) for modulaton
nput when data mode s not n use.
DATA1 MOD
Selects the desred connector(s) for modulaton
nput when data 1 mode (D1) s n use.
DATA2 MOD
Selects the desred connector(s) for modulaton
nput when data 2 mode (D2) s n use.
DATA3 MOD
Selects the desred connector(s) for modulaton
nput when data 3 mode (D3) s n use.
OFF (OPEN)
• OFF (OPEN) : The receved audo s always output
regardless of the squelch condton.
(default)
• ON : The receved audo s output accord-
ng to the squelch condton (open/
close).
50 %
MIC,ACC
• MIC : Use the sgnals from [MIC].
• ACC : Use the sgnals from [ACC1] (pn 4).
• MIC,ACC : Use the sgnals from [MIC] and [ACC1]
(pn 4). (default)
• USB : Use the sgnals from [USB] (B).
ACC
• MIC : Use the sgnals from [MIC].
• ACC : Use the sgnals from [ACC1] (pn 4).
(default)
• MIC,ACC : Use the sgnals from [MIC] and [ACC1]
(pn 4).
• USB : Use the sgnals from [USB] (B).
MIC,ACC
• MIC : Use the sgnals from [MIC].
• ACC : Use the sgnals from [ACC1] (pn 4).
• MIC,ACC : Use the sgnals from [MIC] and [ACC1]
(pn 4). (default)
• USB : Use the sgnals from [USB] (B).
MIC
• MIC : Use the sgnals from [MIC]. (default)
• ACC : Use the sgnals from [ACC1] (pn 4).
• MIC,ACC : Use the sgnals from [MIC] and [ACC1]
(pn 4).
• USB : Use the sgnals from [USB] (B).
☞ Contnued on the next page.
