Cw Normal Side - Icom IC-7600 Instruction Manual

10
SET MODE
■ Others set mode (Contnued)

CW Normal Side

Selects the sdeband used to receve CW n the CW
normal mode from LSB and USB. (default: LSB)
APF Type
Select audo filter shape for APF between SOFT and
SHARP. (default: SOFT)
External Keypad (VOICE)
Sets the external keypad for voce message trans-
msson capablty ON or OFF. (default: OFF)
See page 18 for the equvalent crcut of an external
keypad and connecton.
External Keypad (KEYER)
Sets the external keypad for keyer memory trans-
msson capablty ON or OFF. (default: OFF)
See page 18 for the equvalent crcut of an external
keypad and connecton.
External Keypad (RTTY)
Sets the external keypad for RTTY memory trans-
msson capablty ON or OFF. (default: OFF)
NOTE: Only RTTY memory channels RT1, RT2,
RT3 and RT4 can be transmtted usng wth the
external keypad.
See page 18 for the equvalent crcut of an external
keypad and connecton detals.
External Keypad (PSK)
Sets the external keypad for PSK memory transms-
son capablty ON or OFF. (default: OFF)
NOTE: Only PSK memory channels PT1, PT2,
PT3 and PT4 can be transmtted usng wth the
external keypad.
See page 18 for the equvalent crcut of an external
keypad and connecton detals.
133
LSB
SOFT
• SHARP : The Sharp filter shape rejects nterferng
sgnals more aggressvely.
• SOFT : The Soft filter shape makes dstngush-
ng nose and sgnals easer. The audo
filter wdth s related to the CW ptch set-
tng.
OFF
• OFF : The external keypad does not functon.
• ON : In the phone mode, pushng one of external
keypad swtches transmts the desred voce
message contents.
OFF
• OFF : The external keypad does not functon.
• ON : In the CW mode, pushng one of external
keypad swtches transmts the desred keyer
memory contents.
OFF
• OFF : The external keypad does not functon.
• ON : In the RTTY mode, and wh le the RTTY
decode screen s actve, pushng one of
the external keypad swtches transmts the
desred RTTY memory contents.
OFF
• OFF : The external keypad does not functon.
• ON : In the PSK mode, and wh le the PSK
decode screen s actve, pushng one of
the external keypad swtches transmts the
desred PSK memory contents.
