12
CONTROL COMMAND
D Data content description
• Operating frequency
Command : 00, 03, 05
q w
X X X

• Operating mode

Command : 01, 04, 06
q Operating mode
00: LSB
01: USB
02: AM
03: CW
04: RTTY
Flter settng (w) can be skpped wth command 01
and 06. In that case, "FIL1" s selected wth command
01 and the default filter settng of the operatng mode
s selected wth command 06, automatcally.
• Memory keyer contents
Command : 1A 02
X X X ...... X X
X
• Character's code
Character ASCII code
0–9 30–39
A–Z 41–5A
space
/
?
,
.
@
^

157
e r
X X X X X
q w
X X X X
w Filter setting
05: FM 01: FIL1
07: CW-R 02: FIL2
08: RTTY-R 03: FIL3
12: PSK
13: PSK-R
w–&1 : Text data
q: Channel data
01 M1
02 M2
03 M3
04 M4
Description
Numerals
Alphabetcal characters
20 Word space
2F Symbol
3F Symbol
2C Symbol
2E Symbol
40 Symbol
5E e.g., to send BT, enter ^BT
2A Inserts contest number (can be
used for 1 channel only)
• Band stacking register
Command : 1A 01
t
0 0
q Frequency band code
Code Freq. band Frequency range (unit: MHz)
01
02
03
04
05
06
07
08
09
10
11
w Regster code
Code
01
02
03
For example, when readng the oldest contents n the
21 MHz band, the code "0703" s used.
When sendng the contents, the followng code should
be added after code w.
q, w
X X X X X X ... X X X X X X X X X X X X X X X X X X
e–u Operatng frequency settng
See "• Operatng frequency."
i, o Operatng mode settng
See "• Operatng mode."
!0 Data mode settng
1 byte data (XX)
!0
X X
!1 – !3 Repeater tone frequency settng
!4 – !6 Tone squelch frequency settng
See "• Repeater tone/tone squelch settng."
• Clock 2 offset time setting
Command : 1A 05 0056
q w
X X X X
1.8 1.800000– 1.999999
3.5 3.400000– 4.099999
7 6.900000– 7.499999
10 9.900000–10.499999
14 13.900000–14.499999
18 17.900000–18.499999
21 20.900000–21.499999
24 24.400000–25.099999
28 28.000000–29.999999
50 50.000000–54.000000
GENE Other than above
Registered No.
1 (latest)
2
3 (oldest)
!1 − !3
e−u i, o !0
0: OFF, 1: TONE, 2: TSQL
0: OFF, 1: DATA 1, 2: DATA 2, 3: DATA 3
X X X X XX
Shift direction
00: + (plus)
01: − (minus)
Offset time
0000−2400
!4 − !6
X X
