4
RECEIVE AND TRANSMIT

D RTTY memory transmission

Prevously entered characters can be sent usng the
RTTY memory. Contents of the memory are set usng
the edt menu.
q Durng the RTTY mode operaton, push [DECODE]
(F-3) to select the RTTY decode screen.
w Push [TX MEM] (F-3) to select the RTTY memory
screen.
e Push [1–4/5–8] (F-6) to select the memory bank,
and then push one of the functon keys ([RT1] (F-1)
to [RT4] (F-4) or [RT5] (F-1) to [RT8] (F-4)).
• When no keyboard s connected, the selected memory
contents wll be transmtted mmedately.
• When a keyboard s connected, the memory contents
wll be transmtted mmedately when [F1] to [F8] on
the connected keyboard s pressed, or transmtted after
[F12] s pressed, dependng on auto transmsson/
recepton settng (see below).
• The transmsson date, tme, recepton date and/or tme
may be dsplayed n RX contents screen, dependng on
settng.
For your information
When an external keypad s connected to [MIC]
connector on the front panel, one of RT1 to RT4
RTTY memory contents can be transmtted whle
the RTTY decode screen s selected n the RTTY
mode. (pgs. 18, 133)
D Automatic transmission/reception setting
q Durng the RTTY mode operaton, push [DECODE]
(F-3) to select the RTTY decode screen.
w Push [TX MEM] (F-3) to select the RTTY memory
screen, then push [EDIT] (F-5) to select the RTTY
memory edt screen.
• RTTY memory contents of the Channel 1 (RT1) s
selected.
e Push [RT1..RT8] (F-6) several tmes to select the
desred RTTY memory.
r Push [AUTO TX] (F-5) several tmes to select the
desred operatng opton as follow.
• AUTO TX/RX : Automatcally transmts the selected
• AUTO TX
• AUTO RX
• No ndcaton : Press [F12] on the keyboard
t Push [EXIT/SET] to ext the RTTY memory edt
condton.
49
memory contents, and returns to
receve after the transmsson.
: Automatcally transmts the
selected memory contents. To
return to receve, press [F12] on
the keyboard.
: Press [F12] on the keyboard
to transmt the selected memory
contents. Automatcally returns to
receve after the transmsson.
to transmt the selected memory
contents, and press [F12] agan
to return to receve.
/
DECODE TX MEM
F-3
F-1 F-4 F-1
–
or
RT1 RT4 RT5
• RTTY memory screen
/
DECODE TX MEM
F-3
F-5
EDIT
NOTE: The transcever always functons n the
"AUTO TX/RX" settng when no keyboard s con-
nected.
1–4/5–8
F-6
F-4
–
RT8
RT1..RT8
F-6
EXIT/SET
/
AUTO TX
Auto TX/RX settings
