SSB TBW (WIDE)
Sets the transmsson passband wdth to a wde set-
tng by changng the lower and hgher cut-off fre-
quences.
SSB TBW (MID)
Sets the transmsson passband wdth to a mddle
settng by changng the lower and hgher cut-off fre-
quences.
SSB TBW (NAR)
Sets the transmsson passband wdth to a narrow
settng by changng the lower and hgher cut-off fre-
quences.
Drive Gain
Sets the drve gan level from 0% to 100% n 1%
steps. (default: 50%)
Whle talkng nto the mcrophone, keyng down or
transmttng, rotate the man dal so that the ALC
meter readng s between 30% to 50% of the ALC
scale. (p. 37)
The drve gan s actve for all modes other than the
SSB mode wth speech compressor OFF.
Speech Level
Sets the voce syntheszer audo output level from
0% to 100% n 1% steps. (default: 50%)
Side Tone Level
Sets the sdetone output level from 0% to 100% n
1% steps. (default: 50%)
Side Tone Level Limit
Turns the sdetone output level lmtng capablty ON
or OFF. (default: ON)
When ths tem s set to ON, the CW sdetone s
lnked to the [AF] control untl rotaton of the [AF]
control reaches to the specfed level—further rota-
ton wll not ncrease the volume of the CW sdet-
ones.
100 – 2900
• Lower freq. : 100 (default), 200, 300 and 500 Hz
• Hgher freq. : 2500, 2700, 2800 and
2900 Hz (default)
300 – 2700
• Lower freq. : 100, 200, 300 (default) and 500 Hz
• Hgher freq. : 2500, 2700 (default), 2800
and 2900 Hz
500 – 2500
• Lower freq. : 100, 200, 300 and 500 Hz (default)
• Hgher freq. : 2500 (default), 2700, 2800
and 2900 Hz
50 %
50 %
50 %
ON
• OFF : The CW sdetone level s lnked to the [AF]
control.
• ON : The CW sdetone level s lmted wth the
[AF] control.
☞ Contnued on the next page.
