Icom IC-7600 Instruction Manual page 162

12
CONTROL COMMAND
D Command table (contnued)
Cmd. Sub cmd. Data
1A 05 0095 00
01
0096 00
01
0097 00
01
0098 00
01
0099 00
01
02
03
04
0100 00
01
02
03
04
05
06
07
08
09
10
0101 0010 to
0100
0102 00 to 31 Send/read keyboard repeat speed
0103 00
01
0104 00
01
0105 00
01
02
0106 see p. 158 Send/read waveform color for recevng sgnal
0107 see p. 158 Send/read waveform color for max. hold
0108 00
01
02
0109 00
01
02
0110 00
01
02
0111 00
01
02
0112 00
01
02
155
Description
Voce memory transmsson OFF wth [F1]–
[F4] on the keyboard
Voce memory transmsson ON wth [F1]–
[F4] on the keyboard
Memory keyer transmsson OFF wth [F1]–
[F4] on the keyboard
Memory keyer transmsson ON wth [F1]–
[F4] on the keyboard
CI-V transceve OFF
CI-V transceve ON
CI-V selecton for [USB-B] usage
Decode selecton for [USB-B] usage
300 bps selecton for decode speed
1200 bps selecton for decode speed
4800 bps selecton for decode speed
9600 bps selecton for decode speed
19200 bps selecton for decode speed
Englsh keyboard selecton
Japanese keyboard selecton
Unted Kngdom keyboard selecton
French keyboard selecton
French (Canadan) keyboard selecton
German keyboard selecton
Portuguese keyboard selecton
Portuguese (Brazlan) keyboard selecton
Spansh keyboard selecton
Spansh (Latn Amercan) keyboard selecton
Italan keyboard selecton
Send/read keyboard repeat delay
( 0010=100 msec., 0100=1000 msec.;
50 msec. steps)
(00=2.0 cps, 31=30.0 cps)
Scope ndcaton durng TX OFF
Scope ndcaton durng TX ON
Scope max. hold functon OFF
Scope max. hold functon ON
Flter center selecton for scope center fre-
quency (center mode only)
Carrer pont center selecton for scope cen-
ter frequency (center mode only)
Carrer pont center (Abs. Freq.) selecton for
scope center frequency (center mode only)
SLOW selecton for scope sweep speed n
±2.5 kHz span
MID selecton for scope sweep speed n
±2.5 kHz span
FAST selecton for scope sweep speed n
±2.5 kHz span
SLOW selecton for scope sweep speed n
±5 kHz span
MID selecton for scope sweep speed n
±5 kHz span
FAST selecton for scope sweep speed n
±5 kHz span
SLOW selecton for scope sweep speed n
±10 kHz span
MID selecton for scope sweep speed n
±10 kHz span
FAST selecton for scope sweep speed n
±10 kHz span
SLOW selecton for scope sweep speed n
±25 kHz span
MID selecton for scope sweep speed n
±25 kHz span
FAST selecton for scope sweep speed n
±25 kHz span
SLOW selecton for scope sweep speed n
±50 kHz span
MID selecton for scope sweep speed n
±50 kHz span
FAST selecton for scope sweep speed n
±50 kHz span
Cmd. Sub cmd. Data
1A 05 0113 00 SLOW selecton for scope sweep speed n
±100 kHz span
01 MID selecton for scope sweep speed n
±100 kHz span
02 FAST selecton for scope sweep speed n
±100 kHz span
0114 00 SLOW selecton for scope sweep speed n
±250 kHz span
01 MID selecton for scope sweep speed n
±250 kHz span
02 FAST selecton for scope sweep speed n
±250 kHz span
0115 see p. 158 Scope edge frequences for 0.03 to 1.60 MHz
band
0116 see p. 158 Scope edge frequences for 1.60 MHz to
2.00 MHz band
0117 see p. 158 Scope edge frequences for 2.00 MHz to
6.00 MHz band
0118 see p. 158 Scope edge frequences for 6.00 MHz to
8.00 MHz band
0119 see p. 158 Scope edge frequences for 8.00 MHz to
11.00 MHz band
0120 see p. 158 Scope edge frequences for 11.00 MHz to
15.00 MHz band
0121 see p. 158 Scope edge frequences for 15.00 MHz to
20.00 MHz band
0122 see p. 158 Scope edge frequences for 20.00 MHz to
22.00 MHz band
0123 see p. 158 Scope edge frequences for 22.00 MHz to
26.00 MHz band
0124 see p. 158 Scope edge frequences for 26.00 MHz to
30.00 MHz band
0125 see p. 158 Scope edge frequences for 30.00 MHz to
45.00 MHz band
0126 see p. 158 Scope edge frequences for 45.00 MHz to
60.00 MHz band
0127 00 Auto montor functon OFF durng voce
memory transmsson
01 Auto montor functon ON durng voce mem-
ory transmsson
0128 03 to 10 Send/read voce memory short play tme
(03=3 sec., 10=10 sec.)
0129 05 to 15 Send/read voce memory normal record tme
(05=5 sec., 15=15 sec.)
0130 00 Normal selecton for contest number style
01 "190→ANO" selecton for contest number style
02 "190→ANT" selecton for contest number style
03 "90→NO" selecton for contest number style
04 "90→NT" selecton for contest number style
0131 01 M1 selecton for count up trgger channel
02 M2 selecton for count up trgger channel
03 M3 selecton for count up trgger channel
04 M4 selecton for count up trgger channel
0132 0001 to Send/read present number
9999 (0001=1, 9999=9999)
0133 01 to 60 Send/read CW keyer repeat tme
(01=1 sec., 60=60 sec.)
0134 28 to 45 Send/read CW keyer dot/dash rato
(28=1:1:2.8, 45=1:1:4.5)
0135 00 2 msec. selecton for rse tme of the transmt-
ted CW envelope
01 4 msec. selecton for rse tme of the transmt-
ted CW envelope
02 6 msec. selecton for rse tme of the transmt-
ted CW envelope
03 8 msec. selecton for rse tme of the transmt-
ted CW envelope
04 10 msec. selecton for rse tme of the trans-
mtted CW envelope
0136 00 Normal selecton for paddle polarty
01 Reverse selecton for paddle polarty
0137 00 Straght selecton for keyer type
01 BUG-KEY selecton for keyer type
02 ELEC-KEY selecton for keyer type
0138 00 Mc. up/down keyer functon OFF
01 Mc. up/down keyer functon ON
Description
