4
RECEIVE AND TRANSMIT
D Keyer set mode (contnued)

Paddle Polarity

Ths tem sets the paddle dot-dash polarty.
Keyer Type
Ths tem selects the keyer type for the [ELEC-KEY]
connector on the front panel.
MIC Up/Down Keyer
(Mcrophone's [UP]/[DN] swtches keyer)
Ths tem allows you to set the mcrophone [UP]/
[DN] swtches to be used as a paddle. (The mcro-
phone [UP]/[DN] swtches do not work as a
'squeeze key.')
45
Normal
• Normal and reverse polarty can be selected.
ELEC-KEY
• Straght key, BUG-KEY and ELEC-KEY can be
selected. (default: ELEC-KEY)
OFF
• ON : [UP]/[DN] swtches can be used for CW.
• OFF : [UP]/[DN] swtches cannot be used for CW.
NOTE: When "ON" s selected, the frequency and
memory channel cannot be changed usng the
[UP]/[DN] swtches.
