Interface (Ports & Jacks)
Item Description

Headphone-Out Jack

Headphones or speakers may be connected through this jack. Note: Set your system's volume
to a reduced level before connecting to this jack.
Infrared (FIR) The FIR (far infrared) transceiver at the front of the computer allows the computer to
Transceiver communicate with similarly equipped devices (see "Configuring the Infrared Settings for FIR"
on page 2 - 11).

Line-In Jack

The Line-In jack allows you to play audio sources through the computer's speakers. Note that
audio input through Line-in will default to the mute setting. To set up your audio sources to play
through the Line-in jack go to the Sounds and Audio Devices Windows control panel and
make sure the Mute box is not ticked.

Microphone-In Jack

Plug an external microphone in to this jack to record on your computer.
A

Mini-IEEE 1394 Port

This allows high-speed connection to various peripheral devices, e.g. external disk drives and
digital cameras (see note below).
IEEE 1394
The Mini-IEEE 1394 ports only support SELF POWERED IEEE 1394 devices.
Interface (Ports & Jacks) A - 3
