Attaching Other Displays (for NVIDIA VGA)

If you prefer to use a monitor or flat panel display, connect it to the
1. Attach your external monitor to the DVI-Out Port (or TV to the 7-pin S-Video-Out jack), and turn it on.
2. Go to the Additional Properties in the GeForce Go/Quadro FX Properties control panel tab.
3. Select nView Display Settings.
4. Select the display mode from the nView Display Mode drop box.
5. Click Apply (and Yes to confirm the settings change).
Click the display icon to select it, then click the Device
Settings button to make any adjustments for the select-
ed display (including Screen Resolutions & Refresh
Rates).
Click Detect Displays (button) to automatically update
the attached display information.
Figure D - 5
- nView Display Settings
Windows XP Information
port at the rear of the computer.
DVI-Out
Device Settings
Detect Displays
Video Features D - 9
D
