1.8" Top Case LCD
Flash Top Case Logo
This BIOS item allows
you to enable the serial
port for application pro-
gramming of the top
case logo. After pro-
gramming the
make sure you reset
the option to "Dis-
abled" (default) other-
wise the serial port will
not work.
Figure D - 2
BIOS Advanced
Menu > I/O Device
Configuration
D
D - 2 BIOS Setting

BIOS Setting

Before using the application (LCDAP.EXE) provided on the Device Drivers
and Utilities CD-ROM to program the files displayed on the 1.8" LCD, you
must enable the setting in the BIOS:
1. Restart the computer and press F2 at startup to enter the BIOS.
2. Use the cursor keys to move to and select the Advanced menu.
3. Use the cursor keys to move to and select I/O Device Configuration menu.
logo
4. Select the Flash Top Case Logo item and press Enter to change the
setting to Enabled (see sidebar note).
5. Press F10 to save the settings and exit the program.
Advanced Advanced
I/O Device Configuration
Flash Top Case Logo:
Serial port A:
Serial port B:
Mode:
Parallel port:
Mode:
F1 Help Select Item
Esc Exit Select Menu
PhoenixBIOS Setup Utility
Item Specific Help
Disable:
[Enabled]
Normal serial port A
[Enabled]
function.
[Enabled]
Enable:
[FIR]
Enables serial port A
for programming the top
[Enabled]
case logo image.
[ECP]
Any serial port device
will not be able to
work when this setting
is enabled.
-/+ Change Values F9 Setup Defaults
Enter Select Sub-Menu F10 Save and Exit
BIOS Menus
The BIOS menus
shown are for refer-
ence only. Your com-
puter's menus will
indicate the configura-
tion appropriate for
your model and op-
tions (and are subject
to update).
