System Map: Top View with LCD Panel Open

Wireless Device
Operation Aboard
Aircraft
The use of any portable
electronic transmission
devices aboard aircraft is
usually prohibited. Make
sure the module(s) are
OFF if you are using the
computer aboard aircraft.
Use the AP-key Buttons
to toggle power to the
WLAN, Bluetooth and
PC Camera modules.
1
3
2
4 5
8
9
3
10
Figure 1 - 4 - Top View with LCD Panel Open
System Map: Top View with LCD Panel Open 1 - 7
Quick Start Guide
1. Optional Built-In PC
Camera
2. LCD
3. Speakers (Model A -See
Figure 1 -
3
4. LED Indicators
5. AP-key Buttons
6. Power Button
7. Built-In Microphone
8. Keyboard
9. TouchPad & Buttons
10. Audio "DJ" Display
Panel (Including LED
Indicators)
6
7
3
2)
5
6
4
1
