Changing the Secondary Bay Device

1. Turn off the computer, and turn it over and remove the battery.
2. Move and hold the secondary bay release latch
computer) in the direction of the arrow.
3. Pull the device out of the bay while gripping it at point
2
4. When inserting a new device make sure it is pushed fully into the slot until
the release latch clicks down to lock the device in position.
1
1
(on the left side of the
1
.
3
2
3
Changing the Secondary Bay Device 6 - 9
Upgrading The Computer
Secondary Bay
Hard Disk Option
Note that the Second-
ary (Optional) Device
Bay supports parallel
(PATA) hard disks
only.
Figure 6 - 7
Secondary
(Optional) Bay
Device Removal
