Appendix D: 1.8" Top Case LCD
The 1.8" TFT Top Case LCD can be used to display company logos, personal
photos, animated files etc. The following file formats are supported:
• 24 bit depth Bitmap (.bmp) files which are 128 pixel wide * 160 pixel
high
• 32 bit depth GIF or animated .GIF files which are 128 pixel wide * 160
pixel high
Press to Toggle Power On/Off

1.8" Top Case LCD

1.8" LCD Top
Flash
Case & Battery
Power
The 1.8" LCD will re-
main on even if the
computer is shut down
(and will thus draw
power from the bat-
tery). Power to the 1.8"
LCD may be toggled
on/off by touching the
metal rim which runs
around the LCD. Make
sure you turn off the
LCD after shutting
down the computer.
Figure D - 1
1.8" LCD Power
On/Off
1.8" Top Case LCD D - 1
