Upgrading The Computer
Contact Warning
Be careful not to touch
the metal pins on the
module's connecting
edge. Even the clean-
est hands have oils
which can attract parti-
cles, and degrade the
6
module's
mance.
Figure 6 - 4
Keyboard Release

6 - 6 Upgrading the System Memory (RAM)

Upgrading the System Memory (RAM)
The computer has two memory sockets for 200 pin Small Outline Dual In-line
(SO-DIMM) DDR type memory modules (see
total memory size is automatically detected by the POST routine once you
turn on your computer.
1. Turn off the computer, and remove the battery.
2. Press the three keyboard latches
elevate the keyboard from its normal position (you may need to use a small
screwdriver to do this).
perfor-
3. Carefully lift the keyboard up and disconnect the keyboard ribbon cable by
using a screwdriver to carefully push up the pins
bend the keyboard ribbon cable).
1
- at the top of the keyboard to
1 3
2 3
"Memory" on page E - 2). The
& (be careful not to
4 5
4 5
