Removing the Inverter

1. Remove the battery (page 2 -
(page 2 - 12), CD device (page 2 -
2. Remove the rubber covers and screws
3. Run your finger around the middle of the frame to carefully unsnap the LCD front panel module
4. Remove screws - from the inverter, and disconnect cables
7 8
5. Lift the inverter off the LCD assembly .
11
a.
1
5 4
c.
7
All manuals and user guides at all-guides.com
6), keyboard (page 2 - 8), HDD assembly
12), and bottom case (page 2 -
- from the LCD (Figure 2 -
1 5
b.
2
3
8
(page 2 - 9), CPU (page 2 -
13).
14a).
& from the rear of the inverter.
9 10
6
d.
9
11
Disassembly
Figure 2 - 14
Inverter Removal
10), modem
Sequence
a. Remove the rubber
from the back.
6
covers and screws.
b. Unsnap the LCD
front panel from the
back.
c. Remove the screws
from the inverter.
d. Disconnect the ca-
bles and remove the
inverter.
10
6. LCD Front Panel
11. Inverter
• 7 Screws
• 5 Rubber covers
Removing the Inverter 2 - 17
