Removing the Battery

1. Turn the computer off, place it on a clean, stable surface and turn it over.
-
2. Remove screws (Figure
1 5
3. Remove the battery (and Bay Three device
6
tion of the arrow (Figure 1b)
4. Reverse the process to replace the battery.
a.
2
1
3
4
5
7
All manuals and user guides at all-guides.com
1a).
if applicable) by applying gentle pressure to slide it in the direc-
7
.
b.
Disassembly
Figure 1
Battery Removal
a. Remove the screws.
b. Remove the battery (and
Bay Three Device is ap-
plicable).
6
6. Battery
7. Bay Three Device
• 5 Screws
Removing the Battery 2 - 5
