Removing the Battery

If you are confident in undertaking upgrade procedures yourself, for safety reasons it is best to remove the battery. The com-
puter may come with a 4 cell battery
1. Turn the computer off, and turn it over.
2. Slide the latch in the direction of the arrow (it will remain in place).
1
3. Slide the latch in the direction of the arrow, and hold it in place.
2
4. Slide the battery out of the computer in the direction of the arrow
a.
1
b.
All manuals and user guides at all-guides.com
, or a 10 cell battery .
4 5
a.
2
b.
4
3
.
3
1
5
3
Disassembly
Figure 1
Battery Removal
a. Slide the latch at point 1
in the direction of the ar-
row, and slide the latch at
point 2 towards the un-
lock symbol and hold it in
place.
b. Slide the battery out.
2
4. 4 * Cell Battery
5. 10 * Cell Battery
Removing the Battery 2 - 5
