Right View

On the right side panel, you will find the followings:

Right-Side Stand

Slide this stand outward (together with the left-side stand) to adjust the viewing
angle.

Microphone-in Jack

This audio port accepts sound source to record or to playback when externally
connected microphone is used instead of the built-in one.

Line-in Jack

This audio port accepts sound source to record or to playback when the sound
source comes from other device's audio output than the system's.

Headphone Jack

This audio port accepts sound source to playback if externally connected
headphone is desired instead of the built-in speakers.

Infrared

The wireless communications capabilities are based on IrDA (Infrared Data
Association) standards for cordless connection between the Notebook Computer
and an IrDA-compliant device.

PC Card Type III Expansion Slot

The Type III PC Card slot is located inside a flip-down panel. It allows you to
conveniently attach numerous accessories to the Notebook Computer. It is
equivalent to two Type II PC Cards slots. The ejection button for the upper slot is
located on the left. The ejection button for the lower slot is on the right.

CD-ROM Drive

The 5.25" IDE CD-ROM drive uses the tray loading mechanism for ease of use.
Press the ejection button to load the tray from the drive unit.

Ventilation

The Notebook features a ventilation to dissipate the system's operating heat. Do
not block or obstruct it during operation.
