Using the Information Control Panel

You can use the Information Control Panel (ICP) to silence the audible alarm, and monitor
the power supplies, fans, microprocessor, and cabinet temperature. Other menu functions let
you view component system status, read the firmware revision level, and establish a passcode
to protect SCSI ID options.
The liquid crystal display provides a four line by twenty character display. Of the five
function keys, two move the Menu Selector up or down. The
or returns to the main menu,
backs up one level or cancels an action.
ESCAPE
Menu Selector
MENU ENTER ESCAPE
To display the Main menu, press the
your selection, and then press the
cursor to TURN OFF ALARM and press the
selects the option indicated by the Menu Selector, and
ENTER
System Status Icon
MENU
key. For example, to silence the alarm, move the
ENTER
key selects menu options
MENU
Main Menu
Appears when
more options
are available
above
Appears when
more options
are available
below
Function
Keys
key. Use the up and down arrow keys to make
key.
ENTER
