RAID Mode Performance and Data Integrity
Differences
Three RAID modes provide improved data integrity through data redundancy: RAID 1,
RAID 5, and RAID 3. RAID 0 does not provide data redundancy.
RAID 1 (mirroring) has the smallest impact on performance. It provides neither a severe
performance penalty nor a boost. However, mirroring requires 50% of the raw disk space in
the pack for data redundancy.
RAID 5 (striped data with parity) has improved performance on reads. Write performance is
less due to the time required to calculate parity by performing read-modify-writes on small
block transfers. RAID 5 is more efficient than RAID 1 in terms of the disk space used for
redundancy. A RAID 5 stripe with N disks uses N-1 disks for data, and only one disk for
parity and redundancy information.
RAID 3 is similar to RAID 5, except it stores all parity information on a single disk in the
pack rather than distribute it among the disks as in RAID 5. RAID 3 performance and
space-efficiency characteristics are similar to RAID 5, but RAID 3 provides better
performance for large-block, sequential transfers when using the Controller Read Ahead
option.
RAID 0 (striped data without parity) provides no data redundancy, and thus, no assurance of
data integrity. Data distributes across multiple disk drives; consequently, a failure in any of
the disk drives could result in loss of that data. RAID 0 provides less data integrity than a
single disk drive. However, the performance improvements available through the use of
RAID 0 are greatest. It allows concurrent access to multiple disks on both reads and writes
without the write performance penalty associated with RAID 5.
