Intergraph InterRAID-8e Hardware User's Manual page 48

34
x GB
ADP
x GB
ADP
NOTE The label sheets do not include the numbers 3 and 7 for SCSI IDs. These ID numbers are
used by the disk array and for the MegaRAID controller board.
In a single-bus InterRAID-8e cabinet, all eight RAID disk drives connect to a single
channel. Use the following table to label the drives:
Disk Drive Label
ADP X CH X ID 9
ADP X CH X ID 8
ADP X CH X ID 6
ADP X CH X ID 5
ADP X CH X ID 4
ADP X CH X ID 2
ADP X CH X ID 1
ADP X CH X ID 0
In a dual-bus InterRAID-8e cabinet, the right four RAID disk drives connect to one
channel and the left four RAID disk drives connect to another channel. The following
table shows the channel and ID numbers used for drives installed in a cabinet.
Disk Drive Label
ADP X CH 1 ID 4
ADP X CH 1 ID 2
ADP X CH 1 ID 1
ADP X CH 1 ID 0
ADP X CH 0 ID 4
ADP X CH 0 ID 2
ADP X CH 0 ID 1
ADP X CH 0 ID 0
5. If you have additional cabinets, install the disk drives and complete the drive label
information as appropriate.
6. See the StudioZ RAX System Setup for specific information about drive labeling.
CH ID
0 0 1
CH ID
Cabinet Slots
8 (left)
7
6
5
4
3
2
1 (right)
Cabinet Slots
8 (left)
7
6
5
4
3
2
1 (right)
Blank Disk Drive Label
Number Added
