InterRAID-8e LEDs

The following describes the InterRAID-8e LEDs.

Power On LED

When green, this LED indicates the system is powered on and in normal operating mode.

Channel Mode LED

This LED indicates the status of the disk array by changes in its color and state. The
following table gives the status of the drives attached to a MegaRAID controller.
LED
Steady green
Steady amber
Alternating
green and amber
*Firmware has become corrupted. Call the Customer Response Center at
1-800-633-7248.

Power Supply LED

This LED indicates the status of the power supplies in the cabinet.
LED
Steady green
Steady amber
Off
NOTE See Chapter 9, "InterRAID-8e Power Supply Failures," for information about alarm conditions
when a power supply fails.
InterRAID-8e (SAF-TE Cabinet)
Disk array in fault tolerant state
Disk drive rebuild in progress in the disk
array; or failed disk drive present in the disk
array
Firmware checksum error*
InterRAID-8e
Normal operation
One power supply failed, or
only one power supply present,
or more than four drives
present with two power
supplies present
All power supplies failed
