Summary of Contents for Intergraph Intense 3D Pro 2200
- Page 1 Intense 3D Pro 2200 Installation Guide April 1998 DHA019250...
- Page 2 All warranties given by Intergraph Computer Systems about equipment or software are set forth in your purchase contract. Nothing stated in, or implied by, this document or its contents shall be considered or deemed a modification or amendment of such warranties.
- Page 3 (3) years from the date of purchase. If the product should become defective within the warranty period, Intergraph will, at its option, repair or replace it, provided it is delivered at the purchaser’s expense to the place of purchase or to Intergraph. No other warranty is expressed or implied.
- Page 5 Introduction Congratulations! In choosing Intense 3D Pro 2200, you are equipping your personal computer or personal workstation with powerful and professional 3D graphics. Intense 3D Pro 2200 infuses Intel Pentium , Pentium Pro, and Pentium II computers running the Microsoft Windows NT operating system with workstation-class 3D graphics features and performance.
- Page 6 One slot Dual-screen capability One additional slot Software Intense 3D Pro 2200 software uses the Intense 3D Pro 2200 video display driver. The video display driver installs as a standard Windows NT driver, and provides both GDI and OpenGL graphics compatibility.
-
Page 7: Preparing For Installation
Preparing for Installation Follow these instructions to prepare your computer for Intense 3D Pro 2200. Make Sure Your Computer Is Ready Make sure your IBM PC-compatible computer has the following: A Pentium, Pentium Pro, or Pentium II processor. A high-resolution multi-sync analog RGB monitor. Windows NT 4.0 operating system. -
Page 8: Collect Materials And Tools
2200 hardware in its original packaging to obtain warranty service. Make a Copy of the Video Display Driver Diskette Make a copy of the diskette containing the Intense 3D Pro 2200 video display driver as a precaution. Should anything happen to the copy, you will still have the original diskette. -
Page 9: Installing The Hardware
Installing the Hardware Refer to your computer’s documentation for instructions on opening and closing the computer, identifying PCI expansion slots, disabling on-board graphics acceleration, and adding expansion boards. Add Texture Memory If you want to add texture memory to a Graphics Accelerator, do so before you install the board in the computer. -
Page 10: Start The Installation
Start the Installation To start the installation: 1. Turn off power to the computer and to the monitor. 2. Open the computer to gain access to the PCI expansion slots. 3. If your computer has an installed graphics accelerator, remove it. If your computer has a graphics accelerator integrated onto the system board, disable it. -
Page 11: Using Another Vga Video Display Device
Graphics Accelerator. Refer to the previous figure. 4. Turn on the computer. The video display starts in VGA mode. 5. Install the Intense 3D Pro 2200 video display driver as instructed in Chapter 4, “Installing the Software.” Using Another VGA Video Display Device You can use another VGA video display device, such as a computer system’s onboard VGA controller, instead of using the on-board VGA... - Page 12 2. Connect a video cable (not supplied) from the video output port on the other VGA video display device to the black VGA input port on the Graphics Accelerator. Refer to the figure on the previous page. See Chapter 6, “Technical Information,” for detailed information on ports.
-
Page 13: Installing The Software
5. Click Have Disk. The Install From Disk dialog displays. 6. Type the driver path name (for example, a:\ ), and then click OK. 7. Verify that the Intergraph Intense 3D driver is highlighted in the Change Display dialog, and then click OK. -
Page 14: Configure The Video Display
that you should use the Display option in the Control Panel to select the preferred display resolution. Click OK. 14. If you want to change the display resolution or other display settings, see the following section, “Configure the Video Display.” CAUTION When you select Display in the Windows NT Control Panel, a message displays. -
Page 15: Activate Dual-Screen Behavior
Activate Dual-Screen Behavior If your computer is configured for dual-screen display (with two Intense 3D Pro 2200 Graphics Accelerators installed), the video display driver treats the combined display area of the dual screens as a single canvas that covers both screens. In this Full Canvas style, windows centered on the canvas are split between the two screens. -
Page 17: Getting Help
Getting Help Use the information in this chapter if you encounter a problem with Intense 3D Pro 2200, if you want to get product information or fixes, or if you want to contact Intergraph for help. World Wide Web If your computer has a World Wide Web browser, connect to the Intense 3D Pro pages at http://www.intergraph.com/ics/intense3d... -
Page 18: Warranty Service
Warranty Service Contact the original place of purchase to get warranty service for your Intense 3D Pro 2200 board. If your warranty period has expired, you may still be eligible for warranty service from Intergraph. Refer to the warranty statement at the beginning of this document for details. - Page 19 4. Put the failing board in its original packaging along with your proof of purchase, and return it to Intergraph by the carrier of your choice. You can check the status of your service request by calling the Warranty Administrator at 800-557-4484.
-
Page 21: Technical Information
12V 30 mA +5V 1.5 A +3.3V 5.5 A Monitor Resolutions Intense 3D Pro 2200 supports standard multi-sync monitors, including Intergraph 17-inch and 21-inch multi-sync monitors, at the following resolutions and maximum refresh rates (Hz). Note that i indicates an interlaced frequency. -
Page 22: Vga Support
76 (20), 72i (20), 74 (27), 70i (27) VGA Support The Intense 3D Pro 2200 Graphics Accelerator provides onboard VGA video display support. The maximum resolution supported is 800 x 600, 4 bits per pixel, at 60 Hz vertical refresh. - Page 23 Interfaces The Intense 3D Pro 2200 Graphics Accelerator has three interfaces: a video output port, a VGA input port, and a stereo sync output port. Video Output The video output port is a blue, female, 15-pin, D-Sub connector.
- Page 24 VGA Input The VGA input port is a black, female, 15-pin, D-Sub connector. The port allows connection of a VGA device for the system to use in VGA graphics mode. Signal Name Signal Name Red Analog Video No Connect Green Analog Video Ground Blue Analog Video Monitor ID (bit 0)
- Page 25 Signal Name Ground Ground +12V Stereo Sync No Connect...
