InterServe 8000 Systems

InterServe 8000 systems are shipped from Intergraph Computer Systems with RAID
controllers installed in PCI slots 4 through 8 which should remain in these slots. On a
system with multiple RAID controllers, always use the RAID controller in PCI slot 4 as the
boot controller. On a system with one RAID controller, the controller resides in PCI slot 4.
The following tables show how MegaRAID BIOS lists the installed controllers.
One Controller
Two Controllers
PCI Slot Controller
4 First
5 Second
6 Third
PCI Slot Controller
4 First
5 Second
6 Third
7 Fourth
PCI Slot Controller
4 First
5 Second
6 Third
7 Fourth
8 Fifth
PCI Slot Controller
4 First
PCI Slot Controller
4 First
5 Second
BIOS Configuration
0 (Boot)
2
1
BIOS Configuration
0 (Boot)
3
2
1
BIOS Configuration
0 (Boot)
3
2
1
4
BIOS Configuration
0 (Boot)
BIOS Configuration
0 (Boot)
1
