Setting Up InterRAID-8e Rack-Mount

This chapter describes setting up the rack-mount InterRAID-8e cabinet. If setting up a
deskside (standalone) InterRAID-8e cabinet, see Chapter 2. When setting up the rack-mount
cabinet, you will perform the following tasks:
u
Unpack the equipment.
u
Install the MegaRAID controller (if not pre-installed in the system base unit).
u
Install the cabinet in the rack.
u
Connect the cables.
u
Install and label the RAID disk drives.
u
Power on and configure the system.
Carefully unpack the equipment. The shipping carton contains the following items:
u
MegaRAID controller board (if included)
u
InterRAID-8e cabinet (single or dual-bus)
u
Disk drive boxes containing up to four drives
u
Diskettes containing configuration and utility software
u
Accessories box
The accessories box, included with the cabinet, contains the following items:
u
InterRAID-8e cabinet power cord
u
Handle brackets and screws
u
Rack mounting hardware (shelves, screws, and tinnerman nuts)
u
RAID SCSI cable (two cables, if dual-bus)
u
Key for disk array cabinet
u
Disk drive labels
u
Drive Labeling instruction sheet
u
Power Supply Cord Selection instruction sheet
u
Antistatic Handling instruction sheet
Retain all packaging materials. Equipment returned for repair must be in the original
packaging to obtain warranty service, if provided under your contract agreement.
