Intergraph InterRAID-8e Hardware User's Manual page 106

92
If RAID system is...
RAID 3 or RAID 5 Optimal
RAID 3 or RAID 5 Optimal
RAID 3 or RAID 5 Optimal
RAID 3 or RAID 5
RAID 1 Optimal
RAID 1 Optimal
RAID 1 Degraded
RAID 0
RAID 0
The Advanced Menu from the Logical Drive x pulldown menu allows you to change a
configuration or add a drive to an existing configuation. You can define a maximum of
eight (8) logical drives per RAID controller.
Change Config
Change Config from the Advanced Menu of the Logical Drive x pulldown menu allows you
to change the RAID level and convert a logical drive from degraded to optimal.
To change a RAID level:
1. From the Power Console main menu, place the cursor over the logical drive icon you
want to convert and click the right mouse button. The Chnl x Trgt x pull down menu
displays.
2. Select Advanced Menu, and then select Change Config. The following dialog displays:
You can change to...
RAID 3 or RAID 5 Optimal
RAID 0
RAID 0
RAID 0 Optimal
RAID 3 or RAID 5 Optimal
RAID 0
RAID 0
RAID 3
RAID 0
When You...
Add drives.
Stop parity.
Delete a drive, or add drives.
If a drive fails, you can
configure an Optimal RAID
0 system.
Add drives.
Add drives or delete a drive.
If a drive fails, you can
configure an Optimal RAID
0 system.
Add drives.
Add drives.
