Option
Toolbox
Performance
Monitor
On/Off
Object
Identification
On/Off
Enable/Disable
Sound
Enable/Disable
Alarm Control
Exit

Configuration

The following figure shows the submenu of the Configuration option under Adapter.
The following options are available from this submenu.
Option
Auto
Configuration
Description
Power Console dialog, or to remove the toolbox from the dialog if it is
already displayed.
Select this option to display a graphical representation of the
performance of a logical drive. You can select a bar graph or a line
graph.
Select this option to toggle the Object Identification feature on or off.
Object identification is a feature that identifies all objects displayed in
the Power Console dialog.
Select this option to enable or disable the onboard speaker. To
silence the speaker when it is activated, you must choose Disable
Sound and Disable Alarm Control.
Select this option to enable or disable the system alarm when a drive
failure occurs.
Select this option to quit Power Console. You cannot exit if disk
operations are ongoing. New configurations are not saved unless the
Save Configuration option was selected from the submenu of
Configuration.
Description
Select this option to automatically configure RAID arrays and logical
drives. This option generates the simplest RAID configuration possible
with the current physical drives attached to the selected adapter. Auto
configuration:
1. Attempts to gather physical drives of the same size into groups of five.
2. Attempts to gather the remaining drives into groups with up to three
drives per group.
