Interserve 615, 625, 635, 645 Systems - Intergraph InterRAID-8e Hardware User's Manual

44
The following tables show how MegaRAID BIOS lists from one to five installed controllers.
One Controller
Two Controllers
Three Controllers
Four Controllers
Five Controllers

InterServe 615, 625, 635, 645 Systems

InterServe 615, 625, 635, 645 systems are shipped from Intergraph Computer Systems with
RAID controllers installed in PCI slots 1 through 5 which should remain in these slots. On a
system with multiple RAID controllers, always use the RAID controller in PCI slot 1 as the
boot controller. On a system with one RAID controller, the controller resides in PCI slot 1.
The following tables show how MegaRAID BIOS lists the installed controllers.
One Controller
PCI Slot Controller
1 First
PCI Slot Controller
1 First
2 Second
PCI Slot Controller
1 First
2 Second
3 Third
PCI Slot Controller
1 First
2 Second
3 Third
4 Fourth
PCI Slot Controller
1 First
2 Second
3 Third
4 Fourth
5 Fifth
PCI Slot Controller
1 First
BIOS Configuration
0
BIOS Configuration
1
0
BIOS Configuration
2
1
0
BIOS Configuration
3
2
1
0
BIOS Configuration
3
2
1
0
4
BIOS Configuration
0 (Boot)
