Specifications - Furuno FELCOM 12 Operator's Manual

Transmitting Frequency
Receiving Frequency
Antenna
G/T
EIRP
Modulation
Modulation Rate
Coding
Decoding
Transmission Speed
External Equipment Interface
Internal GPS Receiver (option)
Navigation Equipment Interface Internal GPS Board (option): NMEA0183
Operating Environment
Ship's Mains

SPECIFICATIONS

1626.5 to 1646.5 MHz
1530.0 to 1545.0 MHz
Omnidirectional
Better than -23 dB/K (elevation angle 5˚)
12 to 16 dBW (elevation angle 5˚)
BPSK
1200 sps
Convolutional coding with coding rate
1/2 and constraint length 7
Viterbi decoder
600 bps
Input: GGA, GLL, RMA, RMC, ZDA, VTG, RMB,
WPL, MTW, DBT, VDR, BWC, BWR
Output: GGA, ZDA, GLL, VTG, RMC, GSV
Eight discrete channels, all-in-view
Approx. 50 m, 95% of the time, Horizontal dilution of
position (HDOP)<4
All GPS receivers are subject to degradation of position
and velocity accuracies under the U.S. Department of
Defense.
Above deck equipment
Temperature: -35˚C to +55˚C
Relative humidity: 95% (at 40˚C)
Below deck equipment
Temperature: -20˚C to +55˚C
Relative humidity: 95% (at 40˚C)
Communication unit, Terminal unit and Printer: 24VDC
100/110/120/200/220/240 VAC by optional AC-DC
Power Supply Unit PR-300]
SP-1
