Enabling/Disabling Dnid - Furuno FELCOM 12 Operator's Manual

5-10
DNID with "*" mark are available for use(Refer to Figure
Note:
5-11).
POLLING Message - - - Program Unreserved Data Reporting - - -
DNID : 0004
Sub Address : 000
Receive Data & Time: 97-04-15 00:01 (UTC)
Start Frame: 00030
97-04-15 00:01 (UTC)
Data Report Program has been initiated by Polling.
POLLING Message - - - Initiate Unreserved Data Reporting - - -
DNID :0004
Sub Address : 000
Receive Data & Time: 97-04-15 00:01 (UTC)
Start Frame: 00030
Data Reported (Poll Response)
LES :Southbury
DNID :00004
Member No. :001
Position LAT
LON 124:36.81E
97-04-15 00:06 (UTC)
Successful Data Report Sending.
Figure 5-11 Sample MES signalling channel printout

Enabling/Disabling DNID

DNID can be enabled or disabled as follows:
1. Press up/down arrow key to place the cursor on the desired DNID.
2. Press [Enter] to enable the DNID. (* mark appears.)
Press [Enter] to disable the DNID. (* mark disappears.)
Note: When a DNID is disabled "running data program (poll)"
is displayed and polling is cancelled.
3. Press [Esc] to close the window.
4. To return to the standby display, press [Esc] twice.
"Disable"not permitted in FFA version.
Note:
LES ID : 101 (Southbury)
Member Number : 001 Response: No Response
Interval: 00030
LES ID :101 (Southbury)
Member Number :001 Response: Data Report
Interval: 00030
Date : 97-04-15
Time : 00:03 (UTC)
10:14.03N
