Using The Computer
2
Power Safety
Before attempting to
access any of the inter-
nal components
your notebook please
ensure that the ma-
chine is not connected
to the AC power, and
that the machine is
turned off. Also ensure
that all peripheral ca-
bles, including phone
lines, are disconnected
from the computer.
Figure 2 - 9
Primary Hard
Disk Location

2 - 12 The Hard Disk Drive

The Hard Disk Drive
The hard disk drive is used to store your data in the notebook com-
puter. The primary hard disk is mounted in a removable case and can
be taken out to accommodate other 2.5" IDE hard disk drives with a
height of 9.5 mm. You may have a second, and third hard disk de-
pending on the configuration purchased (see
of
Multiple Hard Disk Use" on page 1 -
The hard disk
1
der the battery, as seen below. Further details on removing and in-
serting the hard disk are available in
Disk" on page 7 -
19).
is accessible from the bottom of your computer un-
"Upgrading the Primary Hard
7.
"Jumper Settings for
1
Hard Disk
