SCU Menu

The initial menu screen will appear as below:
SystemSoft SCU For Intel 845MP chipset
Startup Disks Components Power Exit
Devices
Floppy Drive A = 1.44MB
Hard Drive C = 20005MB
Hard Drive D = 0 MB
Hard Drive E = 0 MB
Hard Drive F = 0 MB
Serial Port 1 = COM 1, 3F8, IRQ 4
Serial Port 2 = COM 2, 2F8, IRQ 3
Parallel Port = LPT1, Addr 378,IRQ 7
Press (Alt) key to activate menus, and cursor keys to navigate. Mouse left
button, spacebar, and <Enter> keys accept menu item. Mouse right button and
<Esc> key cancel current action.
The SCU allows you to make changes to the system settings for pow-
er management, display configuration, hard disk settings, OS set-
tings etc. However please see the note
Settings" on page 5 - 6 regarding adjusting settings in your operating
system (e.g. Windows).
Apr 10, 2002 9:40:02 am
System
CPU Clock = 1500MHz
Memory
Base = 640 KB
Extended = 261120 KB
Shadow = 64 KB
Reserved = 320 KB
Total RAM = 262144 KB
Cache (Ext) = 256 KB
" BIOS Settings V's OS
BIOS Utilities
SCU Screens
The screens which ap-
pear on the following
pages are intended as
a guideline.
It should be noted that
the screen on your par-
ticular computer may
appear a little different-
ly.
Figure 5 - 2
SCU Menu
SCU Menu 5 - 7
