Upgrading The Computer
HDD Orientation
Note the orientation of
the disk in the case.
The rear pins of the
hard disk should point
towards the tail of the
HDD case as indicated
by the arrow
The HDD controller
7
board should be visible
at the top, and the
screws will align with
the holes in the case in
only one way.
Figure 7 - 7
HDD Case
Screws &
Connector Cable
7 - 10 Upgrading the Primary Hard Disk
4. Remove screws
5. Take the HDD out of the case, and pay careful attention to the
orientation of the disk in the case.
6. Insert the new HDD into the case and replace screws
then reconnect the HDD connector cable.
7. Just reverse the removal procedure to install the new HDD
assembly (make sure you reconnect the cable before replacing
the screws
6 .
- , and the HDD connector cable
1 4
- in Figure 7 - 6).
1 2
1
2
4
3
.
5
-
1 4
5
6
,
