Summary of Contents for EUROCOM 888E DREAM MACHINE

  • Page 2 Preface Notice The company reserves the right to revise this publication or to change its contents without notice. Information contained herein is for reference only and does not constitute a commitment on the part of the manufacturer or any subsequent vendor. They assume no re- sponsibility or liability for any errors or inaccuracies that may appear in this publication nor are they in anyway responsible for any loss or damage resulting from the use (or misuse) of this publication.

  • Page 3: Trademarks

    Preface Trademarks This product incorporates copyright protection technology that is protected by method claims of certain U.S. patents and other intel- lectual property rights owned by Macrovision Corporation and other rights owners. Use of this copyright protection technology must be authorized by Macrovision Corporation, and is intended for home or other limited viewing uses only unless otherwise authorized by Mac- rovision Corporation.

  • Page 4: Federal Communications Commission (Fcc) Statement

    Preface Federal Communications Commission (FCC) Statement This equipment has been tested and found to comply with the limits Warning for a Class B digital device, pursuant to Part 15 of the FCC Rules. Use only shielded ca- These limits are designed to provide reasonable protection against bles to connect I/O de- harmful interference in a residential installation.

  • Page 5: Important Safety Instructions

    Preface IMPORTANT SAFETY INSTRUCTIONS When using your telephone equipment, basic safety precautions should always be followed to reduce the risk of fire, electric shock and injury to persons, including the following: 1. Do not use this product near water, for example near a bath tub, wash bowl, kitchen sink or laundry tub, in a wet basement or near a swimming pool.
  • Page 6 Preface IMPORTANTES MESURES DE SÉCURITÉ Certaines mesures de sécurité doivent être prises pendant l’utilisa- tion de matérial téléphonique afin de réduire les risques d’incendie, de choc électrique et de blessures. En voici quelquesunes: Ne pas utiliser l’appareil près de l’eau,, p.ex., près d’une baignoire, d’un lavabo, d’un évier de cuisine, d’un bac à...

  • Page 7: Instructions For Care And Operation

    Preface Instructions for Care and Operation The notebook computer is quite rugged, but it can be damaged. To ensure that does not happen, follow these suggestions: 1. Don’t drop it. Make sure it’s on a stable surface. If the compu- ter falls, the case and other components could be damaged.
  • Page 8 Preface 5. Follow the proper working procedures for the computer. Shut down the computer properly, and close all programs (don’t forget to save your work). Do not turn off any peripheral devices when the computer is on. Do not disassemble the computer by yourself.

  • Page 9: Power Safety

    Preface Power Safety The computer has specific power requirements: Power Safety Warning • Only use a power adapter approved for use with this computer. Before you undertake • Your AC adapter may be designed for international travel but it still any upgrade proce- requires a steady, uninterrupted power supply.

  • Page 10: Battery Precautions

    Preface Battery Precautions • Only use batteries designed for this computer. The wrong battery type Battery Disposal may explode, leak or damage the computer. The product that you • Recharge the batteries using the notebook’s system. Incorrect recharg- have purchased con- ing may make the battery explode.

  • Page 11: Cleaning

    Preface Cleaning Do not apply cleaner directly to the computer, use a soft clean cloth. Do not use volatile (petroleum distillates) or abrasive cleaners on any part of the computer. Servicing Do not attempt to service the computer yourself. Doing so may vio- late your warranty and expose you and the computer to electric shock.

  • Page 12: Travel Considerations

    Preface Travel Considerations Packing As you get ready for your trip, run through this list to make sure the system is ready to go: 1. Check that the battery pack and any spares are fully charged. 2. Power off the computer and peripherals. 3.
  • Page 13 Preface On the Road In addition to the general safety and maintenance suggestions in this preface, and Chapter 8: Troubleshooting, keep these points in mind: Hand-carry the notebook. For security, don’t let it out of your sight. In some areas, computer theft is very common.
  • Page 14 Preface Fly safely. Most airlines have regulations about the use of computers and other electronic devices in flight. These restrictions are for your safety, fol- low them. If you stow the notebook in an overhead compartment, make sure it’s secure. Contents may shift and/or fall out when the compartment is opened.
  • Page 15 Preface Developing Good Work Habits Developing good work habits is important if you need to work in front of the computer for long periods of time. Improper work habits can result in discomfort or serious injury from repetitive strain to your hands, wrists or other joints.
  • Page 16 Preface Remember to: • Alter your posture frequently. • Stretch and exercise your body several times a day. • Take periodic breaks when you work at the computer for long periods of time. Frequent and short breaks are better than fewer and longer breaks.
  • Page 17 Preface Lighting Proper lighting and comfortable display viewing angle can reduce eye strain and muscle fatigue in your neck and shoulders. • Position the display to avoid glare or reflections from overhead light- ing or outside sources of light. • Keep the display screen clean and set the brightness and contrast to levels that allow you to see the screen clearly.

  • Page 18: Table Of Contents

    Preface Contents Notice ............................... I Trademarks ............................II Federal Communications Commission (FCC) Statement ..............III Instructions for Care and Operation ....................VI Power Safety ..........................VIII Battery Precautions .......................... IX Cleaning .............................X Servicing ............................X Travel Considerations ........................XI Introduction ................1-1 Overview .............................. 1-1 The Manual ............................
  • Page 19 Preface Top View .............................. 1-7 Top View with LCD Panel Open ....................1-8 LCD Panel ..........................1-9 LED Power, Battery & E-Mail Status Indicators ............... 1-9 Microphone ..........................1-9 Hot-Key Buttons ......................... 1-9 LED Status Indicators ....................... 1-10 Power Button ..........................1-10 Close Cover Switch ........................
  • Page 20 Preface Hard Disk Drive ........................1-19 IP Sharing Module ........................1-19 Right Side View ..........................1-20 MP3 Player ..........................1-20 Vent ............................1-21 Security Lock Slot ........................1-21 Rear View ............................1-22 DC-In Jack ..........................1-22 Four USB Ports ......................... 1-23 S-Video-In Port (Optional with TV Tuner installed) ...............
  • Page 21 Preface Using The Computer ............2-1 Overview .............................. 2-1 The Power Sources ..........................2-2 AC Adapter ............................. 2-2 Battery ............................2-3 Recharging the Battery with the AC Adapter ................. 2-4 Proper handling of the Battery Pack ................... 2-4 Turning on the Computer ........................2-5 LED Indicators .............................
  • Page 22 Preface Hot-Key Buttons ........................... 2-19 Programming the Hot-Keys ......................2-20 Function Keys ............................ 2-22 The Numeric Keypad ......................... 2-23 Function Keys and Numeric Keypad ..................2-24 TouchPad and Buttons ........................2-25 Configuring the TouchPad and Buttons ..................2-26 Mouse ..............................2-27 Adding a Printer ..........................
  • Page 23 Preface Enabling Other Displays ........................3-10 Clone Mode ..........................3-11 Extended Desktop Mode ......................3-12 Enabling TV Display ......................... 3-14 Power Management Features ......................3-15 Advanced Configuration and Power Interface (ACPI) ..............3-15 Advanced Power Management (APM 1.2) ................... 3-15 Enabling Power Options ........................
  • Page 24 Preface Removing and Replacing the Battery ....................3-25 Audio “DJ” CD Player ........................3-26 Audio “DJ” CD Player Controls (Power On) ................3-28 Configuring the Infrared Settings for FIR ..................3-32 Drivers & Utilities ..............4-1 Overview .............................. 4-1 What to Install ............................4-2 Authorized Driver Message ......................
  • Page 25 Preface Wireless LAN (Win2000) ......................4-9 IP Sharing Module (Win2000) ..................... 4-10 Check Mail (Win2000) ......................... 4-10 Windows XP ............................4-11 Chipset (WinXP) .......................... 4-11 DirectX 8.1 (WinXP) ........................4-11 Intel Application Accelerator (WinXP) ..................4-12 USB 2.0 (WinXP) ......................... 4-12 Audio (WinXP) ..........................
  • Page 26 Preface Failing the POST ..........................5-5 Fatal Errors ..........................5-5 Non-Fatal Errors ......................... 5-5 The System Configuration Utility ......................5-6 Entering Setup ..........................5-6 SCU Menu ............................5-7 Working with the Menu Bar ........................ 5-8 Working with the Pull-Down Menu ..................... 5-9 Working with Sub-Menus ........................
  • Page 27 Preface The MP3 Player ........................... 6-2 Inserting the MP3 Player ........................ 6-3 Secure Digital Cards/MultiMedia Cards ..................6-4 MP3 Player Controls ........................6-5 TV Tuner .............................. 6-7 Installing the TV Tuner ........................6-8 IP Sharing Module ..........................6-10 Cable Connections ........................6-11 Computer Setup ..........................
  • Page 28 Preface Some Things to Watch Out For ....................7-16 Software ............................ 7-16 Setting Up a New HDD ......................7-16 Upgrading the System Memory ......................7-17 Removing the System Memory ....................7-18 Upgrading the Processor ........................7-23 Troubleshooting ..............8-1 Overview .............................. 8-1 Basic Hints and Tips ..........................
  • Page 29 Preface Operation ............................8-24 Appendix A. Specifications ..........A-1 Processor Options ..........................A-1 Core Logic ............................A-2 Structure .............................. A-2 Security ............................... A-2 Memory ............................... A-2 BIOS ..............................A-2 LCD Options ............................A-3 Display ..............................A-3 PC Card ............................... A-3 Storage ..............................A-4 Audio ..............................

  • Page 30: Introduction

    Introduction Chapter 1: Introduction Overview What this chapter covers: • The Manual — how to use it • Quick Start Guide — the minimum you need to know • System Map — navigating around your computer Overview 1 - 1...

  • Page 31: The Manual

    Introduction The Manual This manual refers to the hardware and essential software required to run your notebook computer. Depending on how your system is con- Notes figured, some or all of the features described may already be set up. Check the light colored boxes with the mark Advanced Users above to find detailed...

  • Page 32: Warning Boxes

    Introduction Warning Boxes No matter what your level please pay careful attention to the warning and safety information indicated by the symbol. Also please note the safety and handling instructions as indicated in the Preface. The Manual 1 - 3...

  • Page 33: Not Included

    Introduction Not Included Operating Systems (e.g. Windows 2000 Professional, Windows XP etc.) have their own manuals, as do applications (e.g. word process- ing, spreadsheet and database programs). If you have questions about the operating systems or programs then please consult the ap- propriate manuals.

  • Page 34: Quick Start Guide

    Introduction Quick Start Guide This guide assumes that you are already familiar with computers and can tell at a glance what and where all the key components are. If you Peripheral Devices are not that comfortable with this type of device, then please refer to Please note that pe- the following pages, which give an overview of the system.

  • Page 35: System Map

    Introduction System Map Your computer has a lot of built-in features. Most of these are ena- bled by your operating system. Further explanations of the various Model Differences subsystems are covered in the chapter or pages indicated. You may identify if your computer is Mod- Getting to Know Your Computer el A or Model B from...

  • Page 36: Top View

    Introduction Top View Figure 1 - 2 Top View with LCD Panel Closed 1. LCD Latch 2. LED Power, Battery & E-Mail Status Indicators To open the LCD display: 1. Place the computer on a stable surface. 2. Move the cover latch to the right to release the top cover.

  • Page 37: Top View With Lcd Panel Open

    Introduction Top View with LCD Panel Open Figure 1 - 3 Top View with LCD Panel Open 1. LCD 2. LED Power, Battery & E-Mail Status Indicators 3. Built-In Microphone 4. Hot-Key buttons 5. LED Status Indicators 6. Power Button 7.

  • Page 38: Lcd Panel

    Introduction LCD Panel The computer comes with a 15.0", 15.7" OR 16" TFT (Liquid Crys- tal Display) screen, depending upon the configuration purchased. “LCD Options” on page A - 3 for details. LED Power, Battery & E-Mail Status Indicators These indicators display the system power status, and battery status of the computer.

  • Page 39: Led Status Indicators

    Introduction LED Status Indicators These display the system’s operational status. Refer to “LED Status Indicators” on page 2 - 8 for more information on what the lights mean. Power Button Press this button to turn your computer on or off (see “Turning on the Computer”...

  • Page 40: Keyboard

    Introduction Keyboard The computer has a “Win Key” keyboard including a numeric key- pad. It has the same features as a full-sized desktop keyboard and can Forced Off easily be replaced with a different language keyboard should you de- If the system “hangs”, sire.

  • Page 41: Front View

    Introduction Front View Figure 1 - 4 Front View 1. LCD Latch 2. Audio “DJ” CD Player Control Panel On/Off Switch 3. Previous Track 4. Next Track 5. LCD 6. Play/Pause Audio “DJ” CD Player 7. Stop The built-in standalone audio CD player gives you direct hardware 8.

  • Page 42: Stereo Speakers

    Introduction Note: If you are playing a CD in the audio player you will not be able to use the power button to switch the computer on. Switch the CD audio player off first, then press the power button to turn on the computer.

  • Page 43: Left Side View

    Introduction Left Side View Figure 1 - 5 Left Side View S/PDIF Out Port/ Microphone-In Jack 2 3 4 Line-In Jack Headphone-Out Jack Infrared Transceiver Sony Memory Stick™ Port PC Card Slot Eject Buttons PC Card Slot Floppy Disk Drive Primary Drive Bay (1) 10.

  • Page 44: Line-In Jack

    Introduction Line-In Jack Connect external audio sources to play through your computer’s speakers to this jack. Headphone-Out Jack Headphones may be connected through this jack. Note: Set your system’s volume to a reduced level before connecting to this jack. Infrared Transceiver The infrared transceiver enables communication between the com- Infrared puter and another similarly equipped device, and is 4M bps FIR,...

  • Page 45: Sony Memory Stick Port

    Introduction Sony Memory Stick Port This port accepts Sony’s Memory Stick™ cards which allow for the exchange of data between various types of AV/IT appliances. Dual PC Card Slots There are two Type-II PC Card slots, or the slot may be used for one Type III PC Card (PC Cards were also previously referred to as PC- MCIA).

  • Page 46: Device Bays

    Introduction Device Bays There are two device bays on the left side of your notebook compu- ter: Overheating The primary drive bay (Bay One) will have ONE of the following To prevent your com- interchangeable devices, depending on the configuration purchased: puter from overheating make sure...

  • Page 47: Cd Device

    Introduction CD Device A CD-ROM drive, or DVD-ROM drive, or CD-RW drive, or Com- bination CD-RW and DVD-ROM drive, or DVD-R/-RW drive CD Emergency Eject (12.7mm height) is standard in the primary drive bay (Bay One) de- If you need to manually pending on the model you purchased.

  • Page 48: Hard Disk Drive

    Introduction Hard Disk Drive The internal hard disk drive is used to store your data. You can have up to three hard disks in your computer depending on the configura- Drive Warning tion options purchased. You may have one main HDD, one optional Don’t try to remove the HDD in the modular drive bay (Bay Two), and one optional HDD in hard disk (HDD) while...

  • Page 49: Right Side View

    Introduction Right Side View Figure 1 - 6 Right Side View MP3 Player (Optional) MP3 Player SD/ MMC Slot MP3 Player Release Switch Right Side - MP3 Player In Vent Security Lock Slot MP3 Player Slot (no MP3 Player installed) Right Side - MP3 Player Out MP3 Player Software Installation...

  • Page 50: Vent

    Introduction Vent This enables airflow to prevent the notebook from overheating. Security Lock Slot To prevent possible theft, a Kensington-type lock can be attached to this slot. Locks can be purchased at any computer store. Right Side View 1 - 21...

  • Page 51: Rear View

    Introduction Rear View Figure 1 - 7 Rear View DC-In Jack 4 * USB Ports S-Video-In Port 10 11 12 (Optional) S-Video-Out Port External Monitor (CRT) Port Coaxial TV Antenna Input (Optional) Serial Port IEEE 1394 Port IEEE 1394 Parallel Port The IEEE 1394 port only supports SELF POWERED IEEE 1394 devices.

  • Page 52: Four Usb Ports

    Introduction Four USB Ports Depending on the model you purchase, the USB ports which come with your notebook can be either USB 1.1 compatible or USB 2.0 compatible. USB 1.1 is for low-speed peripherals such as keyboards, mice or scanners while USB 2.0 is for high-speed peripherals such as external HDDs, digital video cameras or high-speed scanners and all USB 1.1 compliant devices.

  • Page 53: S-Video-Out Port

    Introduction S-Video-Out Port Connect your television to your computer and view DVDs, VCDs or anything else your computer can display. You will need an S-Video cable to make the connection. Enable this port from the video driver controls (see “Enabling TV Display” on page 3 - 14).

  • Page 54: Serial Port

    Introduction Serial Port Connect a serial type mouse to this port. IEEE 1394 Port This allows high speed connection to various peripheral devices, e.g. external disk drives and digital cameras (see note below). IEEE 1394 The IEEE 1394 port only supports SELF POWERED IEEE 1394 devices. Printer/Parallel Port This port supports ECP (Extended Capabilities Port) and EPP (En- hanced Parallel Port) 1.7/1.9 modes.

  • Page 55: Ps/2 Type Port

    Introduction PS/2 Type Port Connect an external PS/2 type mouse or keyboard to this port. You can use a “Y” splitter if you want to attach both. RJ-45 LAN Jack This port supports LAN (Network) functions. Note: Broadband (e.g. ADSL) modems usually connect to the LAN port.

  • Page 56: Bottom View

    Introduction Bottom View Figure 1 - 8 Bottom View Vent/Fan Outlets CPU Cover Battery (the primary HDD is located under the battery) Primary Hard Disk Changeable Drive Bay 3 (for TV Tuner or HDD) Modular Drive - Bay 2 Primary Drive - Bay 1 The CPU is not a user serviceable...

  • Page 57: Vent

    Introduction Vent This enables airflow to prevent the notebook from overheating. Overheating Battery To prevent your com- “Battery” on page 2 - 3 for instructions on battery use and care. puter from overheating make sure nothing blocks vent/fan Wireless Network Module outlet while the com- Your notebook computer may have an optional Mini PCI Wireless puter is in use.

  • Page 58: Using The Computer

    Using The Computer Chapter 2: Using The Computer Overview To learn more about using your computer, please read this chapter. This chapter includes: • The Power Sources • Turning on the Computer • LED Indicators • Check Mail Program • The Hard Disk Drive •...

  • Page 59: The Power Sources

    Using The Computer The Power Sources The computer can be powered by either an AC adapter or a battery pack. Shutdown Please note that you AC Adapter should always shut your computer down Use only the AC adapter that comes with your computer. The wrong by choosing the Shut type of AC adapter will damage the computer and its components.

  • Page 60: Battery

    Using The Computer Battery The battery allows you to use your notebook computer while you are on the road or an electrical outlet is unavailable. Battery life varies Battery Release depending on the applications and the configuration you're using. To increase battery life, let the battery discharge completely before re- Remove screws Figure 2 - 2...

  • Page 61: Recharging The Battery With The Ac Adapter

    Using The Computer Recharging the Battery with the AC Adapter The battery pack automatically recharges when the AC adapter is at- tached and plugged into an electrical outlet. If the computer is pow- ered on, and in use, it will take several hours to fully recharge the battery.

  • Page 62: Turning On The Computer

    Using The Computer Turning on the Computer Now you are ready to begin using your computer. To turn it on sim- ply press the power button on the front panel. Power Button as Standby or Hibernate Button When the computer is on, you can use the power button as a hot-key button when it is pressed for less than 4 seconds.

  • Page 63: Led Indicators

    Using The Computer LED Indicators There are two sets of LED indicators (LED Power, Battery & E- Mail Status Indicators and LED Status Indicators) on your com- puter that will display helpful information about the current status of the computer. Figure 2 - 3 LED Power, Battery &...

  • Page 64: Led Power, Battery & E-Mail Status Indicators

    Using The Computer LED Power, Battery & E-Mail Status Indicators Icon Color Description Low Battery Warning Green The computer is on When the battery is critically low, immedi- Blinking Green The computer is in suspend mode ately connect the AC adapter to the comput- Orange The battery is being charged...

  • Page 65: Led Status Indicators

    Using The Computer LED Status Indicators Once your computer is on and in use, the LED status indicators will display the system's operational status. Scroll Lock To enable and disable the Scroll Lock feature, press ScrLk keys simultane- ously. Icon Color Description Green...

  • Page 66: Check Mail Program

    Using The Computer Check Mail Program After you have installed the driver for the Check Mail program (see “What to Install” on page 4 - 2) you may then configure it to give notification when new mail is received. You must be online to re- ceive this notification (note that this program only supports the POP3 protocol), and your default mail program does not need to be open.
  • Page 67 Using The Computer Clicking on Check Mail will bring up the following options menu. Note Check with your Inter- net Service Provider, network administrator or Mail Service provid- er for details on what to put on these pages. You may then configure the options for your mail server, user name, Figure 2 - 6 password.
  • Page 68 Using The Computer Figure 2 - 7 Check Mail Enabled You may also enable an audible warning for received mail by click- ing on Set Mail Wave, and browsing to a .WAV sound file to use for mail notification. Click Enable play wave for mail arrival, and SAVE to save the settings.

  • Page 69: The Hard Disk Drive

    Using The Computer The Hard Disk Drive The hard disk drive is used to store your data in the notebook com- puter. The primary hard disk is mounted in a removable case and can Power Safety be taken out to accommodate other 2.5" IDE hard disk drives with a Before attempting to height of 9.5 mm.

  • Page 70: The Floppy Disk Drive (Fdd)

    Using The Computer The Floppy Disk Drive (FDD) The computer is equipped with a fixed 1.44 MB, 3.5" floppy disk drive module. By default it is drive “A:” and can be used as a boot Media Warning device if properly set in the BIOS (refer to “Boot Device (Startup Don’t try to remove a Menu)”...

  • Page 71: The Cd/Dvd Device

    Using The Computer The CD/DVD Device There are two bays for a combination of a CD-ROM, or DVD-ROM, or CD-RW, or Combination CD-RW and DVD-ROM drive, or Sound Volume Adjustment DVD-R/-RW drive, depending on the model you purchased. You may alternatively have a hard disk or IP sharing module in the mod- How high the sound ular drive bay (Bay Two).

  • Page 72: Handling Cds Or Dvds

    Using The Computer Handling CDs or DVDs Proper handling of your CDs/DVDs will prevent them from being damaged. Please follow the advice below to make sure that the data Media Warning stored on your CD-ROMs/DVD-ROMs can be accessed. When manually eject- Remember to: ing a CD/DVD, DO NOT use a sharpened...

  • Page 73: Dvd Regional Codes

    Using The Computer DVD Regional Codes DVD region detection is device dependent, not OS-dependent. You can select your module’s region code 5 times. The fifth selection is permanent. This cannot be altered even if you change your operating system or you use the module in another computer. Figure 2 - 11 DVD Regional Codes...

  • Page 74: Changing Dvd Regional Codes

    Using The Computer Changing DVD Regional Codes Go to the Control Panel in WindowsXP/Windows 2000 and double- click System > Hardware (tab), click Device Manager, then click the + next to DVD/CD-ROM drives. Double-click on the DVD- ROM device to bring up the Properties menu, and select the DVD Region (tab) to bring up the control panel as seen in “DVD Regional Codes (Windows XP)”...

  • Page 75: The Pc Card Slot

    Using The Computer The PC Card Slot The computer is equipped with a PCMCIA 3.3V/5V slot for two type II PC Cards, or one type III PC Card. Type III PC Cards only fit into the lower socket. Inserting and Removing PC Cards •...

  • Page 76: Hot-Keys

    Using The Computer Hot-Keys The computer has two sets of Hot-Keys, three Hot-Key buttons on the computer, and the function key combinations on the keyboard. Figure 2 - 13 Hot-Keys Hot-Key Buttons These keys access the internet, e-mail or a user-defined application with one quick button press.

  • Page 77: Programming The Hot-Keys

    Using The Computer Programming the Hot-Keys Non-Default E-Mail Hot-Key Function and Browser Programs It is possible to config- Activate the default e-mail program ure both the email and browser hot-keys to open non-default mail browser pro- Activate the default Internet browser grams.
  • Page 78 Using The Computer 1. Right click the Hot-Key driver icon on the taskbar and the following menu will appear. Application.exe You will need to locate the actual application 2. Select Setup from the menu and scroll to Application 1 and executable (.exe) file, not just the shortcut.

  • Page 79: Function Keys

    Using The Computer Function Keys On the bottom-left of the keyboard is the Fn key or Function key. The Fn key allows you to change operational features instantly. To Other Keyboards use the following functions press and hold the Fn key, then press the If your keyboard is appropriate function key (Esc, F6, F10 etc.) located on your key- damaged or you just...

  • Page 80: The Numeric Keypad

    Using The Computer The Numeric Keypad The keyboard has a numerical keypad for easy numeric data input (see “Function Keys and Numeric Keypad” on page 2 - 24). Special Characters Some software appli- To use the keypad simply: cations allow number-keys used with Alt to pro- Activate the Number Lock feature by pressing the NumLk key at...

  • Page 81: Function Keys And Numeric Keypad

    Using The Computer Function Keys and Numeric Keypad Figure 2 - 14 Function Keys & Numeric Keypad 1. Fn Key 2. Audio ON/OFF Toggle 3. Suspend/Resume state Toggle 4. CRT/LCD/LCD and CRT Toggle 5. LCD Brightness Decrease 6. LCD Brightness Increase 7.

  • Page 82: Touchpad And Buttons

    Using The Computer TouchPad and Buttons The pointing device features a sensitive glide pad for precise move- ments. It functions the same way as a two-button mouse (the central Rocker Switch may be configured to function as a “third” button if you prefer).

  • Page 83: Configuring The Touchpad And Buttons

    Using The Computer Configuring the TouchPad and Buttons Once you have installed the TouchPad drivers (see “What to Install” on page 4 - 2) you can configure the functions from the TouchPad driver icon on the taskbar. You may then configure the Touch- Pad tracking, buttons and Rocker Switch etc.

  • Page 84: Mouse

    Using The Computer Mouse You can also add a mouse to your computer. You can use a mouse either through the PS/2 interface or the USB ports (at the rear of the Mouse Driver computer). If you are using an ex- ternal mouse your op- erating system may be able to auto-configure...

  • Page 85: Adding A Printer

    Using The Computer Adding a Printer The most commonly used peripheral is a printer. The following con- ventions will help you to add a printer, however it is always best to refer to the printer manual for specific instructions and configuration options.

  • Page 86: Parallel Printer

    Using The Computer Parallel Printer This is still the most common type of printer. Install Instructions: 1. Set up the printer according to its instructions (unpacking, paper tray, toner/ink cartridge etc.). 2. Attach the parallel cable to the printer. 3. Connect the printer’s parallel cable to the parallel port at the rear of the computer (see “Rear View”...
  • Page 87 Using The Computer 2 - 30...

  • Page 88: Advanced Controls

    Advanced Controls Chapter 3: Advanced Controls Overview This chapter covers: Drivers • Advanced video controls You are unable to use • Power and battery management features most advanced con- • The Audio "DJ" CD player trols until the neces- • Configuring the Infrared settings for FIR sary drivers utilities are properly in-...

  • Page 89: Advanced Video Controls

    Advanced Controls Advanced Video Controls This section is about making adjustments for the LCD, and switching display devices. Protecting the LCD Do not allow any for- Opening the LCD eign objects (i.e. paper or plastic) to get be- As you open the lid, adjust it so you can look at the screen straight tween the lid/LCD and on, without any glare.

  • Page 90: Video Driver Controls

    Advanced Controls Video Driver Controls The video interface lets you change the screen resolution and color output to whatever is most comfortable/efficient for you. This is a Screen Resolution/ Area Note matter of hardware, video memory and the driver for your operating system.

  • Page 91: Making Adjustments For The Display

    Advanced Controls Making Adjustments for the Display The higher the resolution you set the LCD for, the more information the LCD can display on screen. To change the LCD’s resolution and color depth go to the Display Properties control panel: 1.
  • Page 92 Advanced Controls Figure 3 - 3 Advanced Display Properties When the Display Properties control panel is open, click the Ad- vanced (button) to bring up the options tabs. Clicking through these tabs allows you to make any video adjustments you require. Video Driver Controls 3 - 5...
  • Page 93 Advanced Controls Access the menus from ATI taskbar to get further help on display op- tions, TV options etc. Right-click the ATI icon in the taskbar and point to Help or Troubleshooting (Figure 3 - Figure 3 - 4 ATI Help & Troubleshooting 3 - 6 Video Driver Controls...

  • Page 94: Display Devices

    Advanced Controls Display Devices Besides the built-in LCD, you can also use an external CRT connect- ed to the external monitor (CRT) port as your display device. You Drivers may also connect a TV. The following are the display options: You are unable to use most advanced con- 1.

  • Page 95: Attaching A Monitor (Crt)

    Advanced Controls Attaching a Monitor (CRT) If you prefer to use a monitor (CRT), connect it to the External Mon- itor (CRT) port on the rear panel (see “Rear View” on page 1 - 22). Vertical Refresh Rate The vertical refresh rate of your CRT is impor- tant.

  • Page 96: Display Options

    Advanced Controls Display Options TV Support Display Mode Windows XP Windows 2000 You cannot set your flat panel display and Single TV to the same display mode. Multiple - Clone Mode Multiple - Extended Not Available Desktop Mode Single - Either the LCD, CRT or TV as a display device. Table 3 - 1 Multiple (Clone) - The LCD, CRT or TV outputting the same view (you can apply different display modes with different resolutions and refresh...

  • Page 97: Enabling Other Displays

    Advanced Controls Enabling Other Displays In the Advanced ATI Mobility Radeon Properties (Figure 3 - 3 on page 3-5) click on Display to get the other display options, including those for TV (different OS’s will appear with different options). Click the enable/disable button for the display device you wish to use.

  • Page 98: Clone Mode

    Advanced Controls Clone Mode Clone Mode simply shows an exact copy of the Primary display desktop on the other display(s). This mode will drive multiple dis- plays with the same content. Use this feature to display the screen through a projector for a presentation. Each display device can be configured independently as this allows you to set the options for overhead projectors etc., which require specific resolutions and re- fresh rates.

  • Page 99: Extended Desktop Mode

    Advanced Controls Extended Desktop Mode The system supports Extended Desktop (the LCD and a CRT show- ing different views) in multiple display environments in Win- dowsXP, but this mode is NOT supported in Windows2000. An Extended Desktop creates a desktop spanning multiple displays and acts as a large workspace.
  • Page 100 Advanced Controls Figure 3 - 7 Extended Desktop Monitor Arrangement Help Further help is availa- Use the Display Properties control panel to drag the monitors to ble through the menus match the physical arrangement you wish to use. In the example accessed from shown in...

  • Page 101: Enabling Tv Display

    Advanced Controls Enabling TV Display To display desktop images on a TV display, connect the TV to your computer by using an S-Video cable from the TV to the connector at TV Format the rear of the computer (see “Rear View” on page 1 - 22).

  • Page 102: Power Management Features

    Advanced Controls Power Management Features To conserve power, especially when using the battery, your note- book computer has two types of power management available, ACPI OS Note and APM. Power management conserves power by controlling indi- Power management vidual components of the computer (the monitor and hard disk drive) functions will vary...

  • Page 103: Enabling Power Options

    Advanced Controls Enabling Power Options Power Options are enabled through the Control Panel in your Win- dows system (Power Options). With other operating systems you BIOS Settings may have power management available, so check your documenta- You may use the Pow- tion.

  • Page 104: Conserving Power Through Individual Components

    Advanced Controls Conserving Power Through Individual Components Resuming Operation Monitor Standby system To conserve power, you can set the monitor to turn off after a speci- resume from Monitor fied time. or Hard Disk Standby by pressing a key on Hard Disk Standby the keyboard.

  • Page 105: Conserving Power Throughout The System

    Advanced Controls Conserving Power Throughout the System With this function you can stop the notebook’s operation and restart where you left off. This system features Standby and Hibernate System Suspend suspend mode levels (Hibernate mode will need to be enabled by Mode &...

  • Page 106: Standby

    Advanced Controls Standby Standby saves the least amount of power, but takes the shortest time to return to full operation. During Standby the hard disk is turned off, and the CPU is made to idle at its slowest speed. All open applica- tions are retained in memory.

  • Page 107: Hibernate

    Advanced Controls Hibernate Hibernate uses no power and saves all of your information on a part of the HDD before it turns the system off. Although it saves the most power it takes the longest time to return to full operation. You can set your notebook to automatically enter Hibernate mode when the bat- tery power is almost depleted.

  • Page 108: Configuring The Power Button

    Advanced Controls Configuring the Power Button The power button may be set to send the computer in to either Stand- by or Hibernate modes (Figure 3 - 12). If you are running on battery Suspend/Resume power, in Standby mode the LED will flash green, in Hiber- Button nate mode the LED will be off.

  • Page 109: Battery Information

    Advanced Controls Battery Information Please follow these simple guidelines to get the best use out of your battery. Caution Danger of explosion if New Battery battery is incorrectly replaced. Always completely discharge, then fully charge, a new battery be- fore using it (see “Battery FAQ”...

  • Page 110: Battery Faq

    Advanced Controls Battery FAQ How do I completely discharge the battery? Use the computer with battery power until it shuts down due to a low battery. Don’t turn off the computer by yourself even when you see a message that indicates the battery is critically low, just let the com- puter use up all of the battery power and shut down on its own (it is best to disable the Power Options functions in the Control Panel).

  • Page 111: Conserving Battery Power

    Advanced Controls Conserving Battery Power Display Brightness The LCD display consumes a lot of power, so lowering the bright- ness level will save power. Applications and External Devices Different applications and external devices consume battery power even when they are not being used. To conserve battery power we recommend: •...

  • Page 112: Removing And Replacing The Battery

    Advanced Controls Removing and Replacing the Battery For the most part you will not need to remove your battery. If you follow the tips given to manage and extend your battery life on the preceding pages your battery should last a long time. However there may be times when you are required to remove, swap or replace the battery.

  • Page 113: Audio "Dj" Cd Player

    Advanced Controls Audio “DJ” CD Player The built-in standalone audio CD player gives you direct hardware control for audio CDs when the computer is shut down, but has a Turning the Computer On working power source. Note: If you are play- 1.
  • Page 114 Advanced Controls 9. You can control the CD tracking and audio volume from the control panel. 10. The player can be turned off by toggling the ON/OFF switch again. Sound Volume Adjustment How high the sound volume can be set us- ing the volume control knob depends on the setting of the volume...

  • Page 115: Audio "Dj" Cd Player Controls (Power On)

    Advanced Controls Audio “DJ” CD Player Controls (Power On) When the computer is powered-on the Audio “DJ” Player controls will allow you to control over various media players in Windows. The actual functions available will depend on the application used. Function Key Win 2000 Built-In CD Player Table 3 - 2...
  • Page 116 Advanced Controls Table 3 - 3 Function Key WinXP Built-In Media Player Audio “DJ” Function Keys Windows System Volume Up (WinXP) Windows System Volume Down Play/Pause Stop Next Track Previous Track Audio “DJ” CD Player 3 - 29...
  • Page 117 Advanced Controls Table 3 - 4 Function Key InterVideo WinDVD Audio “DJ” Function Keys Windows System Volume Up (InterVideo Windows System Volume Down WinDVD) Play/Pause Stop Next Track Previous Track 3 - 30 Audio “DJ” CD Player...
  • Page 118 Advanced Controls Table 3 - 5 Function Key Power DVD Player Audio “DJ” Function Keys Windows System Volume Up (Power DVD) Windows System Volume Down Play/Pause Stop Next Track Previous Track Audio “DJ” CD Player 3 - 31...

  • Page 119: Configuring The Infrared Settings For Fir

    Advanced Controls Configuring the Infrared Settings for Infrared You will need to change the settings for the infrared device in the Communication BIOS (see “Components Menu” on page 5 - 16) to enable the FIR The infrared transceiv- setting support. er operates on a “Line of Sight”.

  • Page 120: Drivers & Utilities

    Drivers & Utilities Chapter 4: Drivers & Utilities Overview • Windows 2000 Professional • Windows XP This chapter deals with installing the drivers and utilities essential to the operation or im- provement of some of the notebook PC’s sub- systems. The system takes advantage of some newer hardware components for which the lat- est versions of most available operating sys- tems haven’t built in drivers and utilities.

  • Page 121: What To Install

    Drivers & Utilities What to Install The Device Drivers & Utilities + User’s Man- ual CD-ROM contains the drivers and utilities necessary for the proper operation of the note- Navigate (Browse..) to D: book PC. Table 4 - 1 on page 4-4 lists what You will notice that many of the instructions for you need to install manually according to your...

  • Page 122: Authorized Driver Message

    Drivers & Utilities Authorized Driver Message Version Conflict Message If you receive a message telling you that the During driver installation if you encounter any driver you are installing is not authorized “file version conflict” message, please click (Digital Signature Not Found), just click Yes to choose to keep the existing (newer) Yes or Continue Anyway to ignore the mes- version.
  • Page 123 Drivers & Utilities Table 4 - 1 Feature Win 2000 Win XP Installation Chipset page 4 - 5 page 4 - 11 Procedure Microsoft DirectX 8.1 page 4 - 5 page 4 - 11 Intel Application Accelerator page 4 - 5 page 4 - USB 2.0 page 4 - 6...

  • Page 124: Windows 2000 Professional

    Drivers & Utilities Windows 2000 Professional DirectX 8.1 (Win2000) This section covers driver and utility installa- tion instructions for Windows 2000 Profes- 1. Click Start (menu) > Run... sional. 2. Navigate (Browse..) to D:\Driv- ers\VGA\DX81\dxsetup.exe and click 3. To continue click Yes > Install. 4.

  • Page 125: Usb 2.0 (Win2000)

    Drivers & Utilities USB 2.0 (Win2000) double-click the Sounds & Multimedia icon). The USB 2.0 driver is only required for Model 6. Click the Audio tab. B (see “Model Differences” on page 1 - 7. Click Advanced in the Sound Playback Menu.

  • Page 126: Lan (Win2000)

    Drivers & Utilities LAN (Win2000) 6. Navigate (Browse...) to D:\Driv- ers\MODEM\WIN2K. 1. Click Start (menu) > Run... 7. Click Open > OK > Next. 2. Navigate (Browse..) to D:\Driv- 8. Click Finish and close the open ers\LAN\Setup.exe and click OK. windows.

  • Page 127: Hot-Key (Win2000)

    Drivers & Utilities Hot-Key (Win2000) PC Card/PCMCIA (Win2000) 1. Click Start (menu) > Run... 1. Click Start (menu), point to Settings and 2. Navigate (Browse..) to D:\Drivers\AP- click Control Panel. Double-click Sys- KEY\CNK001.EXE and click OK. tem (icon) and then click Device Man- 3.

  • Page 128: Memory Stick (Win2000)

    Drivers & Utilities Memory Stick (Win2000) Wireless LAN (Win2000) 1. Click Start (menu) > Run... 1. Click Start (menu) > Run... 2. Navigate (Browse..) to 2. Navigate (Browse..) to D:\Drivers\Wire- D:\Drivers\MS\setup.exe and click OK. less Lan\GemtekMiniPCI.exe and click 3. Click Next > Next. 4.

  • Page 129: Ip Sharing Module (Win2000)

    Drivers & Utilities IP Sharing Module (Win2000) Check Mail (Win2000) 1. Click Start (menu) > Run... 1. Click Start (menu) > Run... 2. Navigate (Browse..) to D:\Drivers\IP- 2. Navigate (Browse..) to D:\Drivers\E- Share\AUTORUN.EXE and click OK. mail LED\setup.exe and click OK. 3.

  • Page 130: Windows Xp

    Drivers & Utilities Windows XP Chipset (WinXP) 1. Click Start (menu) > Run... This section covers driver and utility installa- 2. Navigate (Browse..) to tion instructions for Windows XP. D:\Drivers\inf_update\infinst_autol.ex e and click OK. 3. When the Setup screen appears click Next >...

  • Page 131: Intel Application Accelerator (Winxp)

    Drivers & Utilities Intel Application Accelerator USB 2.0 (WinXP) (WinXP) The USB 2.0 driver is only required for Model B computers (see “Model Differences” on 1. Click Start (menu) > Run... page 1 - 2. Navigate (Browse..) to D:\Drivers\Intel- IAA\iata_cd.exe and click OK. 3.

  • Page 132: Audio (Winxp)

    Drivers & Utilities Audio (WinXP) date, and the AV Rack control panel should be visible on the desktop. 1. Click Start (menu) > Run... 2. Navigate (Browse..) to Video (WinXP) D:\Drivers\Audio\Setup.exe and click OK > Next. 1. Click Start (menu) > Run... 3.

  • Page 133: Modem (Win Xp)

    Drivers & Utilities Modem (Win XP) cific location (Advanced)” then click Next. 1. If you can see the My Computer icon on 7. Select “Search for the best driver in your desktop (if you cannot see the My these locations.” and select ONLY Computer icon go to step 2) click on it “Include this location in the search:”.

  • Page 134: Hot-Key (Winxp)

    Drivers & Utilities Hot-Key (WinXP) TouchPad (WinXP) 1. Click Start (menu) > Run... 1. Click Start (menu) > Run... 2. Navigate (Browse..) to D:\Drivers\AP- 2. Navigate (Browse..) to KEY\CNK001.EXE and click OK. D:\Drivers\Touchpad\WIN2K_XP\Set 3. Choose the language you prefer. up.exe and click OK. 4.

  • Page 135: Memory Stick (Winxp)

    Drivers & Utilities Memory Stick (WinXP) 1. Click Start (menu) > Run... 2. Navigate (Browse..) to D:\Drivers\MS\setup.exe and click OK. 3. Click Next > Next. 4. Click Finish > Reboot to restart your computer. 4 - 16 Windows XP...

  • Page 136: Wireless Lan (Winxp)

    Drivers & Utilities Wireless LAN (WinXP) IP Sharing Module (WinXP) 1. Click Start (menu) > Run... 1. Click Start (menu) > Run... 2. Navigate (Browse..) to D:\Drivers\Wire- 2. Navigate (Browse..) to D:\Drivers\IP- less Lan\GemtekMiniPCI.exe and click Share\AUTORUN.EXE and click OK. 3.

  • Page 137: Check Mail (Winxp)

    Drivers & Utilities Check Mail (WinXP) 1. Click Start (menu) > Run... 2. Navigate (Browse..) to D:\Drivers\E- mail LED\setup.exe and click OK. 3. To continue click OK, then click the Setup button. 4. Click Continue > OK. 5. Click Yes to restart your computer. 6.

  • Page 138: Bios Utilities

    BIOS Utilities Chapter 5: BIOS Utilities Overview This chapter is about the computer’s built-in software. Your computer comes with built-in BIOS (Basic Input Output Sys- tem) which is an essential set of software routines stored on a chip n tour computer. These routines serve to describe your computer’s hardware to your chosen operating system, and provides an interface between the two.
  • Page 139 BIOS Utilities If your computer has never been set up, or you are making important changes to the system, then you should review this chapter first and note the original settings found in the SCU. Even if you are a begin- ner, keep a record of the settings you find and any changes you make.

  • Page 140: The Power-On Self Test (Post)

    BIOS Utilities The Power-On Self Test (POST) Each time you turn on the computer, the system takes a few seconds to conduct a POST, including a quick test of the on-board RAM. As the POST proceeds, the computer will tell you if there is anything wrong.

  • Page 141: Post Screen

    BIOS Utilities POST Screen Startup Screen: The POST (Figure 5 - SystemSoft MobilePRO BIOS Version 1.01 Copyright 1983 - 1996 SystemSoft Corp. All Rights Reserved If you choose the Fast Boot option in the H8 VERSION 01.15.10 SCU utility, you will 1500MHz Pentium 4 with MMX CPU only see an abbreviat- CPU Microcode Update Rev 003h Complete...

  • Page 142: Failing The Post

    BIOS Utilities Failing the POST Errors can be detected during the POST. There are two categories, “fatal” and “non-fatal”. Fatal Errors These stop the boot process and usually indicate there is something seriously wrong with your system. Take the computer to your service representative or authorized service center as soon as possible.

  • Page 143: The System Configuration Utility

    BIOS Utilities The System Configuration Utility The SCU program tells the system how to configure itself and man- age basic features and subsystems (e.g. port configuration and power BIOS Settings V’s OS Settings management). The settings are stored in a nonvolatile battery and written to the CMOS RAM.

  • Page 144: Scu Menu

    BIOS Utilities SCU Menu The initial menu screen will appear as below: SCU Screens SystemSoft SCU For Intel 845MP chipset Apr 10, 2002 9:40:02 am Startup Disks Components Power Exit The screens which ap- pear on the following Devices System pages are intended as Floppy Drive A = 1.44MB...

  • Page 145: Working With The Menu Bar

    BIOS Utilities Working with the Menu Bar You can use the mouse to navigate around the various menus and submenus of the SCU, or alternatively, you can use the following key combinations: Table 5 - 1 SCU Menu Navigation Keys Keys Action Activates the menu bar...

  • Page 146: Working With The Pull-Down Menu

    BIOS Utilities Working with the Pull-Down Menu Once your desired menu bar item is highlighted, press Enter or left- click with the mouse to see the pull-down menu items. The follow- ing keys allow you to move about the pull-down menu: Table 5 - 2 Pull-Down Menu Keys...

  • Page 147: Working With Sub-Menus

    BIOS Utilities Working with Sub-Menus Some pull-down menu options have an arrow to the right of the entry which indicates a sub-menu is available. Choose these sub-menus by pressing Enter and the screen will be displayed. Navigate through Table 5 - 3 these screens by using the keys in the table below.
  • Page 148 BIOS Utilities The following pages will show some of the menu screens available and will outline some of the main functions which may be set in the SCU. However please remember that most of your settings may be overridden by those of your operating system (see “...

  • Page 149: Startup Menu

    BIOS Utilities Startup Menu SystemSoft SCU For Intel chipset Oct, 15 2002 9:40:02 am Startup Disks Components Power Exit Figure 5 - 3 Date and Time Startup Menu Devices System √ Fast Boot Floppy Drive A = 1.44MB Boot Device Hard Drive C = 20005MB CPU Clock...

  • Page 150: Fast Boot (Startup Menu)

    BIOS Utilities Fast Boot (Startup Menu) Enable this option to eliminate the memory test and other delays at power-up. Boot Device (Startup Menu) Specify which device your computer should look on for an operating system by priority. The most common setting is to look for the dis- kette “A:”...

  • Page 151: Enable Pnp Os Support (Startup Menu)

    BIOS Utilities Enable PNP OS Support (Startup Menu) If you run a Windows OS other than Windows NT 4.0 (e.g. Win- dows 2000 or XP) this should be enabled. The setting will be “En- Password Warning abled” by default. If you choose to set a boot password, NEV- Boot and SCU Passwords (Startup Menu) ER forget your pass-...

  • Page 152: Disks Menu

    BIOS Utilities Disks Menu Here you may enable or disable the different settings and functions for your floppy disk drive, hard disk drive, and CD-ROM/DVD ROM. Figure 5 - 4 Disks Menu (IDE Settings) SystemSoft SCU For Intel chipset Oct 15, 2002 9:40:02 am Startup Disks Components Power Exit...

  • Page 153: Components Menu

    BIOS Utilities Components Menu Here you may setup your COM ports, enable/disable support for a PS/2 Mouse, startup the computer with Number Lock enabled. Figure 5 - 5 Components SystemSoft SCU For Intel chipset Oct 15, 2002 9:40:02 am COM Ports Startup Disks Components Power Exit Menu COM A I/O Settings:...

  • Page 154: Power Menu

    BIOS Utilities Power Menu. Figure 5 - 6 Power Menu SystemSoft SCU For Intel chipset Oct 15, 2002 9:40:02 am Startup Power Disks Components Exit _ Low Power Saving Devices System _ Medium Power Saving _ High Floppy Drive A = 1.44M Power Saving Hard Drive C...

  • Page 155: Exit Menu

    BIOS Utilities Exit Menu From here you may exit the SCU, and you have the option to save the changes you made, or not to do so. You may also choose to re- store the original default settings, or to the last set of custom settings Figure 5 - 7 (these are useful options in case of errors made due to incorrect set- Exit Menu...

  • Page 156: Options

    Options Chapter 6: Options Overview This chapter contains the information on the various optional items which may come with your computer, depending on the configura- tion purchased. If you are unsure please contact your service repra- sentative. The chapter includes information on the following: Warranty Warning •...

  • Page 157: The Mp3 Player

    Options The MP3 Player Figure 6 - 1 Right Side - MP3 The optional MP3 Mobile SD/MMC music player allows you to play Player In & Out and store MP3 music files, and store other data file types. The MP3 player (powered by two AAA batteries) has a built-in port for SD MP3 Player Slot (Secure Digital)/MultiMedia Card (MMC) flash memory cards, a...

  • Page 158: Inserting The Mp3 Player

    Options Inserting the MP3 Player Push the MP3 player into the slot on the right side of the computer. The player should be inserted with the control panels facing upwards as indicated in Figure 6 - 2. Windows will recognize the drive as a removable disk and assign it a letter according to the number of other drives you have in your computer.

  • Page 159: Secure Digital Cards/Multimedia Cards

    Options Secure Digital Cards/MultiMedia Cards SD cards and MMC’s are small, convenient, and durable stamp- sized flash memory cards. SD cards and MMCs are designed to in- Other USB terface with an array of digital devices including PDAs, cellular Supported Devices phones, digital video recorders and digital cameras.

  • Page 160: Mp3 Player Controls

    Options MP3 Player Controls When you have downloaded and copied your MP3 files to the SD card/MMC you may eject the player and use it as a standalone player running on battery power (the player does not need to be powered on when inserted into the slot in the notebook).
  • Page 161 Options Icon Description Headphone-Out Jack Mini USB Port Secure Digital/MMC Slot Power On/Off Table 6 - 1 Audio Volume Up/Down MP3 Player Controls Play/Pause Stop Previous Track Next Track Equalizer Toggle 6 - 6 The MP3 Player...

  • Page 162: Tv Tuner

    Options TV Tuner The optional TV Tuner allows you to watch TV, play music CDs, video conference and capture still images and video on your PC. TV Tuner Remote The remote control unit The TV tuner comes with a remote control unit and accompanying provided with the op- quick start and software guide.

  • Page 163: Installing The Tv Tuner

    Options Installing the TV Tuner The TV Tuner is installed in the bay indicated below. 1. Turn the computer OFF. Line-In Function with TV Tuner 2. Place the computer on a clean, stable surface and turn it over. 3. Remove screws (Figure 6 - With the TV Tuner in- stalled, the line-in jack...
  • Page 164 Options 5. Carefully insert the TV tuner module into the computer, aligning the rear of the TV tuner with the hole at point (see sidebar). 6. The TV Tuner module should align with the connecting pins at Cover point (push firmly down to make sure the module is secure). 7.

  • Page 165: Ip Sharing Module

    Options IP Sharing Module The optional IP sharing module allows you to share your xDSL or cable modem internet connection with up to 4 other computers. You Installing the IP Sharing Module can also share files and printer connections with other machines con- nected to the ports.

  • Page 166: Cable Connections

    Options Cable Connections Your existing cable modem or xDSL connection will connect to the RJ45 LAN jack at rear of your computer. Any other devices will con- nect to one of the four ports on the IP sharing module. When a device is connected the LED indicators will flash.

  • Page 167: Computer Setup

    Options Computer Setup In the following quick setup guide, instructions are grouped by oper- ating system. For full setup and configuration instructions refer to the accompanying manual and quick start guides on the Device Drivers & Utilities + User’s Manual CD-ROM. The following operating systems are covered.

  • Page 168: Windows 2000 Setup

    Options Windows 2000 Setup 1. Go to My Computer > Control Panel > Network and Dial-up Connections. 2. Double-click Local Area Connection. Figure 6 - 9 Win 2000 Setup IP Sharing Module 6 - 13...

  • Page 169: Windows Xp Setup

    Options Windows XP Setup 1. Go to My Computer > Control Panel > Network and Internet Connections > Network Connections. Figure 6 - 10 2. Double-Click Local Area Connection. Win XP Setup 6 - 14 IP Sharing Module...

  • Page 170: Checking The Internet Connection

    Options Checking the Internet Connection Note: To configure this device, you must have Internet Explorer 4.01 or above installed. To see if the IP Sharing device is visible on the local network, go to Start > Run “PING 192.168.1.254” To check if this IP Sharing device is connected to the Internet, run “PING 168.95.192.1 –...
  • Page 171 Options 6 - 16...

  • Page 172: Upgrading The Computer

    Upgrading The Computer Chapter 7: Upgrading The Computer Overview This chapter contains the information on upgrading the computer. Follow the steps outlined to make the desired upgrades. If you have any trouble or problems you can contact your service representative for further help.

  • Page 173: When Not To Upgrade

    Upgrading The Computer When Not to Upgrade These procedures involve opening the system’s case, adding and sometimes replacing parts. Power Safety Warning You should not perform any of these upgrades if: Before you undertake any upgrade proce- • your system is still under warranty or a service contract dures, make sure that •...

  • Page 174: Upgrading The Primary Drive Bay (Bay One) Cd Device

    Upgrading The Computer Upgrading the Primary Drive Bay (Bay One) CD Device The interchangeable CD device installed in the primary drive bay (Bay One) on the right/front (as you look at the left side of the com- puter) will depend on what configuration you purchased. If you wish to change or upgrade this device follow this procedure.
  • Page 175 Upgrading The Computer 5. Remove screw 6. Remove screws 7. Apply gentle pressure at point to push the battery up and out of the computer. Figure 7 - 2 Battery Removal and CD Device Screw Location 7 - 4 Upgrading the Primary Drive Bay (Bay One) CD Device...
  • Page 176 Upgrading The Computer 8. Gently push the device out of the bay (you may need to use a screwdriver to do this). 9. Slide the new device into the bay, then secure it with screw (Figure 7 - 10. Replace the changeable drive bay cover, and secure with the screws (Figure 7 - 11.

  • Page 177: Upgrading The Modular Drive Bay (Bay Two) Device

    Upgrading The Computer Upgrading the Modular Drive Bay (Bay Two) Device What is installed in the modular bay (Bay Two) on the left/rear (as you look at the left side of the computer) will depend on what con- figuration you purchased. If you wish to change or upgrade this de- vice follow the same procedure as “Upgrading the Primary Drive Bay (Bay One) CD Device”...

  • Page 178: Upgrading The Primary Hard Disk

    Upgrading The Computer Upgrading the Primary Hard Disk The hard disk drive is used to store your data internally in the com- puter. The primary hard disk is mounted in a removable case under battery bay, and can be taken out to accommodate other 2.5" IDE hard disk drives with a height of 9.5 mm.

  • Page 179: Removing The Battery

    Upgrading The Computer Removing the Battery 1. Shut the computer down and turn it over. 2. Remove screws 3. Apply gentle pressure at point to push the battery up and out of the computer. Figure 7 - 5 Removing the Battery 7 - 8 Upgrading the Primary Hard Disk...

  • Page 180: Removing The Hard Disk Assembly

    Upgrading The Computer Removing the Hard Disk Assembly 1. Remove screws from the HDD assembly. 2. Release the HDD connector cable HDD Cables 3. Remove the HDD assembly from the bay. The illustrated HDD cable may differ from the one in your model depending on the con- figuration purchased.
  • Page 181 Upgrading The Computer 4. Remove screws , and the HDD connector cable 5. Take the HDD out of the case, and pay careful attention to the orientation of the disk in the case. HDD Orientation 6. Insert the new HDD into the case and replace screws then reconnect the HDD connector cable.

  • Page 182: Upgrading The Hard Disk In Bay Two

    Upgrading The Computer Upgrading the Hard Disk in Bay Two If you wish to upgrade or replace the hard disk installed in the mod- ular bay (Bay Two) on the left/rear (as you look at the left side of the computer) follow the same procedure as “Upgrading the Prima- ry Drive Bay (Bay One) CD Device”...
  • Page 183 Upgrading The Computer Once you have removed the existing assembly you may then install the new hard disk in its place. 1. Remove screws , and disconnect cable 2. Take the HDD assembly out of the case. 3. Remove screws , from the HDD assembly (note the ori- entation of the disk within the assembly brackets).

  • Page 184: Upgrading The Hard Disk In Bay Three

    Upgrading The Computer Upgrading the Hard Disk in Bay Three The changeable drive bay under the computer can be used to house either the optional TV tuner, or an optional hard disk drive. To upgrade the hard disk in the changeable drive bay please perform the following steps: 1.
  • Page 185 Upgrading The Computer 4. Lift the cover off the changeable drive bay and set it aside. 5. Remove screws 6. Lift the HDD assembly out of the bay. Figure 7 - 11 HDD Assembly Removal 7 - 14 Upgrading the Hard Disk in Bay Three...
  • Page 186 Upgrading The Computer 7. Remove screws and the connector , to release the HDD from the case. 8. Insert the new hard disk and reverse the procedures to install it. Figure 7 - 12 HDD Case Screws & Connector Cable Upgrading the Hard Disk in Bay Three 7 - 15...

  • Page 187: Some Things To Watch Out For

    Upgrading The Computer Some Things to Watch Out For Software HDD System Allow the system to auto-detect the new HDD, or if necessary, run Warning the SCU Utility in the BIOS to customize the system (see “Disks New HDDs are blank. Menu”...

  • Page 188: Upgrading The System Memory

    Upgrading The Computer Upgrading the System Memory The computer has two memory sockets for 200-pin PC-266MHz or PC-200MHz DDR Small Outline Dual In-line Memory Modules (SO-DIMM). The main memory can be expanded up to 1024MB, and accepts 128/256/512MB modules. The total memory size is automatically detected by the POST routine once you turn on your computer.

  • Page 189: Removing The System Memory

    Upgrading The Computer Removing the System Memory 1. Turn off the computer. 2. Press the two keyboard latches at the top of the keyboard to elevate the keyboard from its normal position as in Figure 7 - (you may need to use a small screwdriver to do this). Figure 7 - 13 Removing the Keyboard...
  • Page 190 Upgrading The Computer 4. Carefully loosen the locking collar on the keyboard cable by using a small flat-head screwdriver to gently pry the locking col- lar away from its base (when replacing the connection, make sure the connector is oriented in the same way). 5.
  • Page 191 Upgrading The Computer 7. Locate the Memory sockets Contact Warning Be careful not to touch the metal pins on the module’s connecting edge Even the clean- est hands have oils which can attract parti- cles, and degrade the module’s perfor- mance.
  • Page 192 Upgrading The Computer 11. Insert a new module holding it at about a 30° angle and fit the connectors firmly into the memory slot. Figure 7 - 16 Memory Insertion 12. The module will only fit one way as defined by its pin alignment. Make sure the module is seated as far into the slot as it will go.
  • Page 193 Upgrading The Computer 15. Reconnect the keyboard ribbon cable and carefully tighten the locking collar, insuring that the cable will not come free. 16. Replace the keyboard by insuring the five tabs at the base of the keyboard fit into place (you will find these under the Fn, Spacebar (2), arrow and Enter keys - see Figure 7 - 17).

  • Page 194: Upgrading The Processor

    Upgrading The Computer Upgrading the Processor If you want to upgrade your computer by replacing the existing pro- Warranty cessor with a faster/new one you will need to contact your customer service representative. We recommend that you do not do this your- The CPU is not a user self, since if it is done incorrectly you may damage the processor or serviceable...
  • Page 195 Upgrading The Computer 7 - 24...

  • Page 196: Troubleshooting

    Troubleshooting Chapter 8: Troubleshooting Overview Should you have any problems with your computer, before consult- ing the service center, you may want to try to solve the problem your- self. This chapter lists some common problems and their possible solutions. This can’t anticipate every problem, but you should check here before you panic.

  • Page 197: Basic Hints And Tips

    Troubleshooting Basic Hints and Tips Many of the following may seem obvious but they are often the so- lution to a problem when your computer appears not to be working. •Power: Is the computer actually plugged into a work- ing electrical outlet? If plugged into a power strip, make sure it is actually working.
  • Page 198 Troubleshooting •Display Choice: Press Fn + F6 to make sure the system is not set to “external only” display (see “Attaching a Monitor (CRT)” on page 3 - •Boot Drive: Make sure there are no floppy disks in the drive when you start up your machine (this is a common cause of the message “Invalid system disk - Replace the disk, and then press any key”).

  • Page 199: Backup And General Maintenance

    Troubleshooting Backup and General Maintenance • Always backup your important data, and keep copies of your OS and programs safe, but close to hand. Don’t forget to note the serial num- bers if you are storing them out of their original cases e.g. in a CD wal- let.

  • Page 200: Viruses

    Troubleshooting Viruses • Install an Anti-Virus program and keep the definitions file (the file which tells your program which viruses to look for) up to date. New computer viruses are discovered daily, and some of them may seriously harm your computer and cause you to lose data. Anti-Virus programs are commercially available and the definitions file updates are usually downloadable directly from the internet.

  • Page 201: Upgrading And Adding New Hardware/Software

    Troubleshooting Upgrading and Adding New Hardware/ Software Warranty The CPU is not a user • Do not be tempted to make changes to your Windows Registry unless serviceable part. you are very sure of what you are doing, otherwise you will risk Opening this compart- severely damaging your system.
  • Page 202 Troubleshooting • Make sure you have installed the drivers for any new hardware you have installed (latest driver files are usually available to download from vendor’s websites). • Thoroughly check any recent changes you made to your system as these changes may affect one or more system components, or software programs.

  • Page 203: Power

    Troubleshooting Power Problem Possible Cause Possible Solution You turned on the The battery is missing or Check the battery bay, make sure the battery is power but it doesn’t incorrectly installed. present and seated properly (the design of the battery work.
  • Page 204 Troubleshooting Problem Possible Cause Possible Solution You are losing The battery does not fully battery power too charge because of prolonged quickly. inactivity. Battery Charging Make sure the battery is totally used up before recharg- ing, and make sure you recharge the battery to full ca- pacity each time...
  • Page 205 Troubleshooting Problem Possible Cause Possible Solution The notebook feels The system is using too much Reduce the computer’s power consumption. Make too hot. power or is not properly sure the notebook is properly ventilated and the fan ventilated. port is not blocked. If this doesn’t cool it down, put the system into Suspend mode or turn it off for an hour.
  • Page 206 Troubleshooting Problem Possible Cause Possible Solution A beeping sound is The battery power is nearly Connect the AC adapter to your computer. heard and the low- used up. battery indicator is A beep isn’t heard The battery power is nearly used up and the volume when the low-battery control may be turned down.

  • Page 207: Display

    Troubleshooting Display Problem Possible Cause Possible Solution Nothing appears on The screen saver is Press any key or touch the TouchPad to return to your screen. activated. display. The LED power indicator, The system is in a power saving mode.Toggle the , is blinking green.
  • Page 208 Troubleshooting Problem Possible Cause Possible Solution The screen images The screen controls need to Toggle the screen control key combinations Fn + F9 aren’t clear. be adjusted. and F10 (see “Opening the LCD” on page 3 - The viewing angle of the LCD Adjust the position of the LCD.

  • Page 209: Hard Disk Drive (Hdd)

    Troubleshooting Hard Disk Drive (HDD) Problem Possible Cause Possible Solution The computer takes Data saved on the hard disk Operate the scan disk or disk defragmenter to check longer during drive may be lost or for any lost or damaged data. Startup.

  • Page 210: Boot Password

    Troubleshooting Boot Password Problem Possible Cause Possible Solution You forget the boot If you choose to set a boot password, NEVER forget password. your password. The consequences of this could be serious. If you cannot remember your boot password you must contact your vendor and you may lose all of the information on your hard disk.

  • Page 211: Floppy Disk Drive (Fdd)

    Troubleshooting Floppy Disk Drive (FDD) Problem Possible Cause Possible Solution The floppy disk drive The floppy disk is not Format the disk (you may do this by right-clicking the will not write data to formatted. disk icon in My Computer in Windows and choosing disk.

  • Page 212: Audio

    Troubleshooting Audio Problem Possible Cause Possible Solution The Audio “DJ” CD The computer is turned ON Check your computer is not turned on (or running in a Player will not turn (see “Audio “DJ” CD power saving mode), and if it is then shut it down, then on (nothing appears Player”...

  • Page 213: Cd Device

    Troubleshooting CD Device Problem Possible Cause Possible Solution The compact disc The compact disc is dirty. Clean it with a CD-ROM cleaner kit. cannot be read. Media Warning When manually ejecting a CD/DVD disc, DO NOT use a sharpened pencil or similar object which may break, and become lodged in the hole.
  • Page 214 Troubleshooting Problem Possible Cause Possible Solution A music compact There may be a problem with Refer to your operating system manual for more disc can be read the disc hardware or information on the software and make sure you have while a data disc can software.

  • Page 215: Pc Card

    Troubleshooting PC Card Problem Possible Cause Possible Solution The system cannot The PC Card is not inserted Remove the card and reinsert it aligning the PC Card recognize the PC into the socket or inserted with the slot. Push the card in until it locks into place. Card.

  • Page 216: Keyboard And Mouse

    Troubleshooting Keyboard and Mouse Problem Possible Cause Possible Solution Unwelcome The NumLk is turned ON (the Press and release the Fn & NumLk keys. numbers appear is lit). when typing. I have installed a You have not installed the Make sure you read the documentation which comes new external driver to enable any extra with any new external device, and make sure you...

  • Page 217: Printer

    Troubleshooting Printer Problem Possible Cause Possible Solution The printer cannot The printer power is off or the Check all connections and cables and then try to be added to the printer is not correctly reinstall the driver. system or will not connected to the computer.
  • Page 218 Troubleshooting Problem Possible Cause Possible Solution The printer is a network All networks are configured differently so please check printer and it is not properly with your network administrator to get the correct connected to the network. setup. The operation mode for the The default operation mode for the parallel port (ECP) parallel port set in the BIOS is backward compatible with other operation modes...

  • Page 219: Operation

    Troubleshooting Operation Problem Possible Cause Possible Solution The system won’t The Audio “DJ” CD Player is Toggle the ON/OFF switch off the CD Player. start up when the ON (see “Audio “DJ” CD power button is Player” on page 3 - 26).
  • Page 220 Troubleshooting Problem Possible Cause Possible Solution The system does not No power saving options are Use one of the Power Options presets. go into suspend or enabled. save to disk when the battery is low. The infrared device The drivers (if supplied with Please read the documentation which comes with any doesn’t work.
  • Page 221 Troubleshooting 8 - 26...

  • Page 222: Appendix A. Specifications

    Appendix A Appendix A. Specifications Model Differences Model differences: Model A and Model B are identical except for the specification differences listed in this Appendix. You may identify if your computer is Mod- el A or Model B from Processor Options the video card.

  • Page 223: Core Logic

    Appendix A Core Logic • Intel® 845/845E + ICH3 Structure • Fully PC99 Compliant • ACPI 1.0B Compliant • PC2001 Compliant Security • Security (Kensington® Type) Lock Slot • BIOS Password Memory • 64 bit data bus system memory • Two 200-pin DDR SODIMM sockets, supporting DDR SDRAM SODIMM (2.5V) - DDR200 or DDR266 compliant •...

  • Page 224: Lcd Options

    Appendix A LCD Options • 15.0" 1600 x 1200 UXGA TFT (Model A) • 15.7" 1280 x 1024 SXGA TFT (Models A & B) • 16.0" 1600 x 1200 UXGA TFT (Model B) • 16.0" 1280 x 1024 SXGA TFT (Model B) Display •...

  • Page 225: Storage

    Appendix A Storage • One fixed FDD • One changeable 2.5" 9.5mm primary HDD • Changeable primary drive (Bay One) for one of the following: DVD-ROM (12.7mmH) 24 * CD-ROM 24 * CD-RW Combo Drive (DVD-ROM + CD-RW) DVD-R/-RW • Built-in modular drive (Bay Two) for one of the following: DVD-ROM (12.7mmH) 24 * CD-ROM 24 * CD-RW...

  • Page 226: Audio

    Appendix A Audio • AC'97 2.2 compliant interface • Compatible with Sound-Blaster PRO™/ 16 • S/PDIF Digital output (5.1 CH) for DVD content and Stereo Audio • Built-in microphone • Audio DJ • Advanced Wavetable Synthesizer • 2 built-in speakers •...

  • Page 227: Interface

    Appendix A Interface • Built-in TouchPad (PS/2) • Four USB 1.1 ports (Model A) • Four USB 2.0 ports (Model B) • One IEEE 1394 port • One S-Video-Out jack for TV output • One S-Video-In jack (option included with TV Tuner only) •...

  • Page 228: Power Management

    Appendix A Power Management • Supports ACPI v1.0B • Supports APM v1.2 • Soft Off by system power button • Supports suspend to disk • Battery low suspend • Resume from alarm • Close-cover switch Power • Full Range 120 watts AC adapter - AC in 100~240V, 47~63Hz •...

  • Page 229: Environmental Spec

    Appendix A Environmental Spec • Temperature Relative Humidity ° ° • Operating: 5 C~ 35 Operating: 20% ~ 80% ° ° • Non-Operating: -20 C ~ 60 Non-Operating: 10% ~ 90% Physical Dimensions • 360 (w) x 299 (d) x 54.5 (h) mm Weight •...
