Extended Desktop Mode - EUROCOM 888E DREAM MACHINE User Manual

Advanced Controls
3
3 - 12 Enabling Other Displays

Extended Desktop Mode

The system supports Extended Desktop (the LCD and a CRT show-
ing different views) in multiple display environments in Win-
dowsXP, but this mode is NOT supported in Windows2000. An
Extended Desktop creates a desktop spanning multiple displays and
acts as a large workspace.
To get this effect:
1. Attach your external monitor to the External Monitor (CRT)
port, and turn it on.
2. Go to the Advanced Display Settings (see
Properties" on page 3 -
3. Select the Displays tab (see
4. Click the enable/disable button
you wish to use (Monitor).
5. Click Apply and image will appear on the display device.
6. Click Yes to accept the settings and OK to save the changes.
7. Use the Display Properties window to select the second mon-
itor by clicking on the icon, or select it from the "Display:" pop-
up menu.
8. Click "Extend my Windows desktop onto this monitor."
9. Use the Display Properties control panel to drag the monitors
to match the physical arrangement you wish to use.
"Advanced Display
5).
"Displays Tab" on page 3 -
for the display device
10).
