EUROCOM 888E DREAM MACHINE User Manual page 190

4. Carefully loosen the locking collar on the keyboard cable by
using a small flat-head screwdriver to gently pry the locking col-
lar away from its base (when replacing the connection, make
sure the connector is oriented in the same way).
5. Lift the keyboard away and carefully set it aside.
6. Remove the small screws at positions
ing plate, and lift the plate up off the computer.
1
- from the shield-
1 3
1
2 3
Upgrading The Computer
Figure 7 - 14
Removing the
Shielding Plate
Upgrading the System Memory 7 - 19
7
