Bottom View

1
2 5
1
3
6
7
4
3
Introduction
Figure 1 - 8
Bottom View
1.
Vent/Fan Outlets
2. CPU Cover
3. Battery (the primary
HDD is located
under the battery)
4. Primary Hard Disk
5. Changeable Drive
Bay 3 (for TV Tuner
or HDD)
6. Modular Drive -
Bay 2
7.
Primary Drive -
Bay 1
CPU
The CPU is not a user
serviceable part.
Opening this compart-
ment, or accessing the
CPU in any way, may
violate your warranty.
