EFI Pi6500 Pro Configuration Manual page 89

3
3-13 Network Setup
Static IP (Token Ring)
change.
Subnet Mask (Token Ring)
following values:
• if the IP address starts with a number less than 128
255.0.0.0
• 255.255.0.0
•
255.255.255.0
Be sure to confirm the subnet mask setting with your network administrator
N :
OTE
before proceeding. In some cases the required setting may be different from those
listed.
Gateway
If your TCP/IP network has a gateway, and users outside the gateway print to the
Pi6500 Pro using TCP/IP, enter the gateway address. Obtain the correct gateway
address from your network administrator.
—Use this option to get the gateway address automatically for printing with
IP Auto
TCP/IP. This option is available only if you selected DHCP or BOOTP as the
protocol.
If you select a DHCP or BOOTP protocol and later change it to RARP, you must
return to Gateway Setup and set Get Gateway Address Automatically to No. You can
then set the address manually. This is because RARP does not support automatic
assignment of the gateway address.
—This option is available only if you answered No to Get Gateway Address
IP Static
Automatically, or if you selected RARP as the protocol. Use this option to set the
gateway address for printing with TCP/IP. If your network uses a gateway, you must
change the default to a correct gateway address for your network.
—Click to assign the Pi6500 Pro a static IP address that will not
—If you need to set the subnet mask, enter one of the
if the IP address starts with a number from 128 through 191
if the IP address starts with a number greater than 191
