EFI Pi6500 Pro Configuration Manual page 83

3
3-7 Network Setup
For this Network or
Connection Type
AppleTalk over Ethernet
TCP/IP over Ethernet
IPX/SPX over Ethernet
Parallel
For this Network or
Connection Type
TCP/IP over Token Ring
IPX/SPX over Token Ring
The available network types, and the setups that you use with them, are summarized in
the following tables.
Use this Port Setup
Ethernet Setup AppleTalk Setup
Ethernet Setup TCP/IP Setup: Ethernet Setup
Ethernet Setup IPX/SPX Setup
Parallel Port Setup
If the Token Ring option is installed, you have the following additional options:
Use this Port Setup
Token Ring Setup TCP/IP Setup: Token Ring Setup
Token Ring Setup IPX/SPX Setup
You can modify these Network Setup options:
• Ports—Ethernet, Token Ring, or parallel port
• Protocols—TCP/IP, AppleTalk, and IPX/SPX
• Print Services—NetWare printing (PServer), Windows print sharing (SMB),
LPD printing (TCP/IP), and HTTP support (WWW)
Use this Protocol Setup
–
Use this Protocol Setup
Use this Service Setup
AppleTalk printing (PAP) is
enabled automatically.
Web Services (if TCP/IP is
also enabled)
Web Services
lpr printing is enabled
automatically.
PServer (NDS, Bindery, or
both)
Web Services (if TCP/IP is
also enabled)
–
Use this Service Setup
Web Services
PServer (NDS, Bindery, or
both)
Web Services (if TCP/IP is
also enabled)
