4-16 Setting up Network Servers
T F W T
O SET UP IERY EB OOLS ON THE
1. Perform Pi6500 Pro Setup and enable TCP/IP.
In Network Setup, choose Protocol Setup and perform TCP/IP Setup and Ethernet
Setup.
2. Set a valid, unique IP address for the Pi6500 Pro, and then set the subnet mask and a
gateway address if necessary.
3. Exit TCP/IP Setup and exit Protocol Setup.
4. Choose Service Setup, and choose Web Services Setup.
5. For Enable Web Services, select Yes.
6. Exit Service Setup and exit Network Setup, and select Yes at the Save Changes screen.
T F W T
O SET UP IERY EB OOLS ON A COMPUTER
1. Enable TCP/IP networking.
2. Assign the workstation has a valid, unique IP address, and then set the subnet mask.
Set a gateway address if necessary.
3. Install an Internet browser that supports the Java language and frames.
Make sure Java is enabled.
See Getting Started for more information on supported browsers and other
Fiery WebTools requirements.
