EFI Pi6500 Pro Configuration Manual page 49

2
2-19 Network Setup options
IP Address
[127.0.0.1]
Enter the Pi6500 Pro IP address for Token Ring. This IP address, unlike an IP address
set automatically, remains the same if you reboot the Pi6500 Pro. You must change the
default to a valid address for your network.
Subnet Mask
[255.255.255.0]
This option lets you modify the subnet mask for printing with TCP/IP over Token
Ring. The subnet mask is set to 255.255.255.0 by default. To set the subnet mask,
enter one of the following values:
• 255.0.0.0
•
255.255.0.0
•
255.255.255.0
Confirm the subnet mask setting with your network administrator before
N :
OTE
proceeding. In some cases the required setting may be different from those listed.
if the IP address starts with a number less than 128
if the IP address starts with a number from 128 through 191
if the IP address starts with a number greater than 191
