EFI Pi6500 Pro Configuration Manual page 140

A
A-2 Token Ring Network Option
Back view of the Pi6500 Pro with the Token Ring option installed
Turn off the Pi6500 Pro before connecting it to any network device.
!
Do not attach cable to both Token Ring connectors.
N :
OTE
T
O CONNECT CABLE TO THE
1. Turn off the Pi6500 Pro.
2. Connect cable from the Token Ring MAU to the Pi6500 Pro Token Ring card.
Configure the NetWare, Windows NT, or UNIX server to print to the Pi6500 Pro (see
the next two sections). Then proceed to page 2-1 for Pi6500 Pro Setup.
P 6500 P
I RO
Token Ring
connectors
