2-10 Setting up the Pi6500 Pro
For this Network or
Connection Type
AppleTalk over Ethernet
TCP/IP over Ethernet
IPX/SPX over Ethernet
Parallel
For this Network or
Connection Type
TCP/IP over Token Ring
IPX/SPX over Token Ring
T N
O ACCESS
1. Confirm that the network cable is connected to the Pi6500 Pro.
2. Choose Network Setup from the main Setup menu.
3. Choose Port Setup from the Network Setup menu.
The available network types, and the Setup areas that pertain to them, are summarized
in the following tables.
Use this Port Setup
Ethernet Setup AppleTalk Setup
Ethernet Setup TCP/IP Setup: Ethernet Setup
Ethernet Setup IPX/SPX Setup
Parallel Port Setup
If the Token Ring option is installed, you have these additional options:
Use this Port Setup
Token Ring Setup TCP/IP Setup: Token Ring Setup
Token Ring Setup IPX/SPX Setup
S
ETWORK ETUP OPTIONS
During Network Setup, the Pi6500 Pro queries the network for zones, servers, and
server-based queues. If you perform Network Setup without a connected and
functioning network, default settings are used that may not meet your needs.
Use this Protocol Setup
—
Use this Protocol Setup
Use this Service Setup
AppleTalk printing (PAP) is
enabled automatically
LPD Setup
Web Services Setup
Windows Setup
Port 9100 Setup
IPP Setup
PServer Setup (NDS,
Bindery, or both)
—
Use this Service Setup
LPD Setup
Web Services Setup
Windows Setup
PServer Setup (NDS,
Bindery, or both)
