EFI Pi6500 Pro Configuration Manual page 107

4
4-3 Pi6500 Pro on a NetWare 5.x network with NDPS
In Pi6500 Pro Setup, make sure you have enabled TCP/IP (page 2-15) and LPD
printing (page 2-22) on the Pi6500 Pro. You can ping the Pi6500 Pro (page 4-20) to
verify that TCP/IP communication is successful.
Setting up the Pi6500 Pro on a NetWare 5.x network
Depending on the security needs at your organization, you can set up the Pi6500 Pro
as a Public Access printer or a Controlled Access printer. The following procedure
describes setting up a Public Access printer. You can then convert this type of printer to
Controlled Access if necessary. For more information, see your NetWare
documentation.
In the following procedure, "Atlas" is an example of an NDPS Manager name;
N :
OTE
"Aero" is an example of a Printer Agent name.
T P 6500 P
O SET UP THE I
1. In NetWare Administrator, double-click the NDPS Manager object you have created.
2. In the Details window for the NDPS Manager object, click the Printer Agent List
button.
The list of Printer Agents appears.
3. Click New.
The Create Printer Agent dialog box appears.
4. In the Printer Agent (PA) Name field, enter a name.
5. Under Gateway Types, select Novell Printer Gateway, and click OK.
P A
RO AS A UBLIC CCESS PRINTER
:
