EFI Pi6500 Pro Configuration Manual page 130

5
5-4 Administering the Pi6500 Pro
After this Setup screen
Enable AppleTalk
(Network Setup>Protocol
Setup>AppleTalk Setup)
Protocol Setup or Service
Setup (Network Setup)
Protocol Setup or Service
Setup (Network Setup)
Frame Type selection
(Network Setup>Protocol
Setup>IPX/SPX Setup)
Token Ring Setup
Enable NDS
(Network Setup>Service
Setup>PServer Setup>
NDS Setup)
Network Setup messages
This message
No AppleTalk zone found.
You must first enable
a network port.
You must first enable
a network port.
Invalid frame size.
Warning! IPX network
number is zero.
Can't detect Token Ring
hardware.
Token Ring hardware not
installed or not functioning.
Can't autodetect the ring
speed. No device on ring.
No NDS trees found.
Means
The Ethernet network cable is not attached to the
connector on the Pi6500 Pro, or the network cable is not
plugged into the hub or network. If your AppleTalk
network has zones, and you want to specify a zone for the
Pi6500 Pro, you must connect the network cable to the
Pi6500 Pro before performing AppleTalk Setup.
It also could mean that the AppleTalk network does not
have zones. Zones are not required for printing to the
Pi6500 Pro. Press OK to continue.
At least one network port (Ethernet or Token Ring) must
be enabled in Port Setup before Protocol Setup or Service
Setup.
You must enable Ethernet in Port Setup before Protocol
Setup or Service Setup.
The network hub is not connected to a Novell machine
when the Pi6500 Pro tries to bind.
No other IPX machine can be found on the network, or
the network hub is not connected to the network, when
the Pi6500 Pro tries to bind. When this occurs, the
network number defaults to zero.
Pi6500 Pro queries the Token Ring hardware. Error
indicates that some components are not installed, are not
installed correctly, or not installed in the correct device. An
unsupported Token Ring board may be in use. Check with
your authorized service/support center.
The Pi6500 Pro is trying to detect the current ring speed,
but it is the only machine on the token ring network.
Connect another machine to the token ring network first,
before connecting the Pi6500 Pro.
No NDS trees were found on the Novell network. Check
that IPX frame types are properly set.
