Chapter 5
Tabs (2)
Riser Board
Figure 5-4. Removing the Accessory Slot Cover
10. If necessary, remove the riser board from the PCI slot.
You may leave the riser board in place with smaller PCI boards, but you
will need to remove the riser board from the PCI slot for larger PCI boards.
11. Slide the accessory board into the PCI slot on the riser board as shown in
Figure 5-5.
Installing Additional Boards
Latch
Tab Rest
Slot Cover
41
