HP D7171A - NetServer - LPr Manual

Ultra hot swap hard disk drive and tray.
Hide thumbs
HP NetServer
Ultra Hot Swap Hard Disk Drive
and Tray
HP Part Number 5969-5925
Printed in February 2000

Advertising

   Related Manuals for HP D7171A - NetServer - LPr

   Summary of Contents for HP D7171A - NetServer - LPr

  • Page 1

    HP NetServer Ultra Hot Swap Hard Disk Drive and Tray HP Part Number 5969-5925 Printed in February 2000...

  • Page 2: Audience Assumptions

    Hewlett-Packard assumes no responsibility for the use or reliability of its software on equipment that is not furnished by Hewlett-Packard.

  • Page 3: Table Of Contents

    Contents 1 Installation Procedure................. 1 Installing the Hot Swap Hard Disk Drive in a Tray (optional) ......1 Unpacking and Shipping................2 Installing the Hot Swap Hard Disk Drive ............3 Removing the Hot Swap Hard Disk Drive ............4 2 Disk Drive Characteristics................

  • Page 5: Installation Procedure, Installing The Hot Swap Hard Disk Drive In A Tray (optional)

    1 Installation Procedure This guide describes how to attach an Ultra hot swap hard disk drive to a hot swap tray and install the hard disk drive in your computer. Additionally, this guide provides the cautions and instructions for removing and storing the hard disk drive.

  • Page 6: Unpacking And Shipping

    Chapter 1 Installation Procedure Figure 1-1. Hot Swap Hard Disk Drive and Tray Installation Unpacking and Shipping Your system has a shipping plug to ensure that the hot swap hard disk drive is not damaged while it is being transported. Save this plug. If you plan to transport your system, reinstall your shipping plug as shown in Figure 1-2.

  • Page 7: Installing The Hot Swap Hard Disk Drive

    Chapter 1 Installation Procedure Figure 1-2. Shipping Plug Installing the Hot Swap Hard Disk Drive CAUTION Use one of the six (6) vertical shelves in the system. Do not attempt to install the hot swap hard disk drive in the horizontal shelves.

  • Page 8: Removing The Hot Swap Hard Disk Drive

    Chapter 1 Installation Procedure Holding the hard disk drive as shown in Figure 1-3, slide the hot swap hard disk drive slowly into the shelf until it stops. Press the lever down as far as it will go. Figure 1-3. Installing the Hot Swap Hard Disk Drive Removing the Hot Swap Hard Disk Drive 1.

  • Page 9

    Chapter 1 Installation Procedure Figure 1-4. Removing the Hot Swap Hard Disk Drive...

  • Page 11: Disk Drive Characteristics, Netware And Dos

    2 Disk Drive Characteristics The proper settings for the following items will depend on the operating system (NetWare, MS-DOS, OS/2, Windows NT, UNIX, or Banyan Vines) and corresponding version number: Extended Translation setting for the controller Partitions, logical drives or divisions for the hot swap hard disk drive For non-UNIX systems, partition and logical hot swap hard disk drive sizes also depend on: Partition type (Bootable or Non-bootable)

  • Page 12: Os/2 And Windows Nt

    Chapter 2 Disk Drive Characteristics OS/2 and Windows NT NOTE Configure the controller with “Extended Translation for Drives > 1 GB ” enabled. Table 2-2. Partitioning Information for OS/2 and Windows NT Maximum Bootable Partition Maximum Non-bootable Drive Operating FAT or HPFS NTFS HPFS NTFS...

  • Page 13: Unix And Banyan Vines

    Chapter 2 Disk Drive Characteristics UNIX and Banyan Vines Table 2-3. Partitioning Information for UNIX Maximum Size Maximum Number Extended Divisions Operating Translation File system Partitions System for > 1 GB Partition (division) on Disk Partition Drive SCO UNIX Disabled Disk 1 GB (root) capacity...

  • Page 15: Application Alerts, D4903a Cooling Requirements, D3604a/b Storage System/6 Using Ultra Scsi Drives

    3 Application Alerts D4903A Cooling Requirements The D4903A mass storage device is the first of a family of high performance 10K RPM drives. Adequate cooling is very important. The D4903A drive is currently supported in the LH Plus, LH Pro, LD Pro, LX Pro, LXe Pro, and Storage System/6.

  • Page 17: A Warranty And Support, Hardware Warranty, Hp Repair And Telephone Support

    Refer to the HP Warranty and Service/Support Booklet section of your HP NetServer system documentation for instructions on how to obtain HP repair and telephone support. HP World Wide Web Site Refer to the following World Wide Web (WWW) site for technical specifications on Hewlett-Packard hard disk drives: http://www.hp.com:80/netserver/support/news_main.html...

  • Page 19: B Regulatory Information

    The product herewith complies with the requirements of the following directives, and carries the CE-mark accordingly: o Low Voltage Directive 72/23/EEC o EMC Directive 89/336/EEC 1) This product was tested in a typical configuration with a Hewlett-Packard NetServer computer and peripherals. Cupertino, February 8, 2000 Nigel Marrion/Quality Engineering Manager European Contact: Your local Hewlett-Packard Sales and Service Office or Hewlett-Packard GmbH, Department ZQ / Standards Europe, Herrenberger Straße 130, D-7030 Böblingen (FAX: + 49-7031-143143)
