Appendix A
Table A-4. HP Netserver Hardware Specifications
Processors
Intel Pentium III (up to 2 processors) processors, at supported
speeds of 866, 933 MHz and 1 GHz, with 256 KB level 2
cache on processor
Chipset
RCC LE chip set with 133 MHz bus speed support
Memory
Supports up to four SDRAM DIMMS for a maximum of 4 GB.
Supported DIMM types: 128 MB, 256 MB, 512 MB and 1 GB
unbuffered (registered), 72 bits wide, ECC single-bit
correcting, multi-bit detecting.
Video
Supports up to 1600x1200, @ 65K colors, using an Embedded
ATI Rage XL video chip with 4 MB SGRAM/SDRAM. Refer
to Table A-5, "Video Display Modes" for more details.
SCSI
Embedded Symbios Ultra-160 SCSI dual channel controller;
160 MB/s transfer rate with two 68-pin connectors
IDE
Embedded Enhanced-IDE dual channel controller
LAN
Two Embedded Intel 82559 10/100 PCI Fast Ethernet
Controllers; with Wake-on-LAN and Alert-on-LAN
enabled/disabled via BIOS setup
PCI Bus
One 32/64-bit, 33 MHz speed, 5 volt PCI slot on riser board
I/O
One serial/management port and one bi-directional parallel port
with ECP/EPP high-speed support; one PS/2 mouse, one PS/2
keyboard, and two USB connectors
CD-ROM
One Slimline CD-ROM drive; IDE interface; 24x speed
Table A-5. Video Display Modes
Max. Refresh
Rate @ 256
Resolution Colors
640x480
800x600
1024x768
1152x864
1280x1024
1600x1200
Max. Refresh
Rate @ 65K
Colors
200 Hz 200 Hz
200 Hz 200 Hz
150 Hz 150 Hz
120 Hz 120 Hz
100 Hz 100 Hz
76 Hz 76 Hz
Specifications
Max. Refresh
Rate @ 16.7M
Colors
200 Hz
160 Hz
120 Hz
85 Hz
85 Hz
Not available
